Product: HVAC MACHINE TOOLS
COIL SIZE: 48" WIDE
COIL ID 20" hYDR CLAMPING RANGE: 18 1/2" - 20 3/4"
MAX COIL OD: 39"
MAX COIL WEIGHT (3 TONS): 6600 LBS
SPEED: 0-100'/ MIN
HYDR SYSTEM PRESSURE: 0-15 MPA
MAIN MOTOR: 4HP, 220V (only), 3 PHASE
HYDRAULIC MOTOR: 4HP, 220V, 3 PHASE
HYDRAULIC TANK CAPACITY: 10 GALLONS
MACHINE DIMENSIONS: 122" X 73" X 78"
MACHINE WEIGHT: 5,220 LBS
Standard Features:
ISO 9001 certified
American design and Taiwan quality machine
Hydraulic clamping for coil
With sensors to avoid the sheet metal touches the floor.
Hydraulic front support arm
Hydraulic top support arm
One year warranty for parts
