With the Vulcan VCBB24B V-series range, chefs can sear and grill proteins on its 24-inch-wide charbroiler and store ingredients and supplies in its cabinet base. To complement other pieces of back-of-house equipment, this 24-inch-wide by 36 3/4-inch-deep by 40 3/4-inch-tall piece's front, front top ledge, burner box, sides, base, and stub back are made of durable stainless steel, which resists corroding, denting, and scratching through daily use. The storage base is lined with universal rack guides to accommodate different sizes of food pans, and its removable shelf can store spices, condiments, cooking utensils, and other supplies. A stainless steel cabinet door encases the base to conceal stored contents. For stability during use, this unit is positioned on 6-inch legs that can be raised or lowered to level the unit on bumpy or sloped flooring.
To achieve a smoky grilled flavor, the Vulcan VCBB24B LP-gas-powered range is lined with heavy-duty cast iron grates that create appetizing grill lines. Because the grates are slanted, fat can drain from proteins, and flare-ups are less likely to occur. All four burners have individual pilot lights and controls so chefs can adjust each burner's heat as needed, and the char radiants absorb and direct heat toward the unit's top. For even heat distribution, the charbroiler is built with stainless steel supercharger burner dividers, and for thorough cleaning after use, staff can quickly remove the four grates.
Product Details
Part of the V series
24-in.-wide charbroiler
4 burners with individual pilots and controls
Stainless steel supercharger burner divider panels
4 heavy-duty, slanted cast iron grates
Char radiants
Stainless steel front, front top ledge, burner box, sides, base, and stub back
4-in. stub riser
Cabinet base includes 1 removable shelf, universal rack guides, and stainless steel door
Positioned on 6-in. adjustable legs
65,000 BTU
Dimensions & Utilities
24 in. W x 36 3/4 in. D x 40 3/4 in. H
Powered by LP gas
1 1/4-in. diameter front gas manifold
3/4-in. rear gas connection
Product Features
Specifications
Manufacturer
Vulcan
Application
Heavy Duty
Base
Storage
BTU / Burner
16250
Burner Configuration
Standard
Burner Style
None
Burner Type(s)
None
Depth (in)
36.75
Gas Type
LP
Heat
Gas
Height (in)
36
Installation Type
Freestanding
Number of Burners
None
Number of Ovens
No Oven
Product
Gas Ranges
Product Type
Cooking Equipment
Range Configuration
Charbroiler
Rating
Best
Series
V Series
Total BTU
65000
Vent
Stub Back
Warranty
1-year Limited Parts & Labor
Width (in)
24
Weight
405.00
Manufacturer: Vulcan
Application: Heavy Duty
Base: Storage
BTU / Burner: 16250
Burner Configuration: Standard
Burner Style: None
Burner Type(s): None
Depth (in): 36.75
Gas Type: LP
Heat: Gas
Height (in): 36
Installation Type: Freestanding
Number of Burners: None
Number of Ovens: No Oven
Product: Gas Ranges
Product Type: Cooking Equipment
Range Configuration: Charbroiler
Rating: Best
Series: V Series
Total BTU: 65000
Vent: Stub Back
Warranty: 1-year Limited Parts & Labor
Width (in): 24
Weight: 405.00
