Vulcan VCBB36S 36" Gas Range W/ Full Charbroiler & Standard Oven, Natural Gas

So chefs can sear, grill, broil, roast, and bake various ingredients, the Vulcan VCBB36S V-series heavy-duty range features a 36-inch-wide charbroiler top and standard oven base. This two-in-one, 36-inch-wide by 41 7/8-inch-deep by 40 1/2-inch-tall unit is great for kitchens with limited space and has a stainless steel front, front top ledge, burner box, sides, base, and stub back to resist denting, scratching, and corroding while prolonging its service life. This natural-gas-powered unit is fitted with 6-inch legs that can be raised or lowered to stabilize the unit on bumpy or sloped surfaces.
Because the charbroiler's six burners each have separate pilot lights, heat controls, and grates, staff can cook different products simultaneously. The integrated char radiants direct heat toward the surface, while the supercharger burner divider panels establish a uniformly heated surface. The slanted, heavy-duty cast iron grates create appetizing grill marks on chicken, steak, and vegetables. For simple cleaning, this unit features an extra-deep crumb tray, and the grates can be lifted off.
The Vulcan VCBB36S commercial range's standard oven base has a 27-inch-wide by 27-inch-deep by 13-inch-tall interior cavity with a porcelain base, interior door panel, and sides for easy cleaning. This piece of equipment comes with a rack that can be raised or lowered in three positions. For smooth pan insertion and retrieval, it's built with a heavy-duty counterweight hinged door. Staff can simply adjust the oven's temperature from 150 to 550 degrees Fahrenheit with the thermostat to accommodate changing baking requirements.

Range Details





Featured in the V series
Stainless steel front, front top ledge, sides, base, and stub back
36-in.-wide charbroiler with 6 burners
Separate pilot lights and controls for each burner
6 sloped, lift-off heavy-duty cast iron grates
Char radiants and stainless steel supercharger burner dividers
Extra-deep stainless steel crumb tray
99,000 BTU

Standard Oven Details





Operating temperature: 150-550 degrees F
Includes 1 oven rack
3 rack positions
1 door with counterweight hinges
Simple-to-clean porcelain interior door panel, sides, and base
6-in. adjustable stainless steel legs
50,000 BTU

Dimensions & Utilities





Oven interior: 27 in. W x 27 in. D x 13 in. H
Overall: 36 in. W x 41 7/8 in. D x 40 1/2 in. H
Powered by natural gas
1 1/4-in. diameter front gas manifold
1 1/4-in. rear gas connection
149,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Additional Info
Contact Customer Service for altitudes above 2,000 feet

Application
Heavy Duty

Base
Standard Oven

BTU / Burner
16500

Burner Configuration
Standard

Burner Style
None

Burner Type(s)
None

Charbroiler Location
Full

Charbroiler Width (in)
36

Controls
Thermostatic

Depth (in)
36.75

Gas Inlet Size
1.25

Gas Type
NG

Heat
Gas

Height (in)
36

Installation Type
Freestanding

Max Temp
550

Number of Burners
None

Number of Ovens
Single

Product
Gas Ranges

Product Type
Cooking Equipment

Rack Positions per Standard Oven
3

Racks per Standard Oven
1

Range Configuration
Charbroiler

Rating
Best

Series
V Series

Standard Oven BTU/hr
32000

Standard Oven Dimensions
27"W x 27"D x 13"H

Total BTU
149000

Vent
Stub Riser

Warranty
1-year Limited Parts & Labor

Width (in)
36

Weight
685.00

Manufacturer: Vulcan
Additional Info: Contact Customer Service for altitudes above 2,000 feet
Application: Heavy Duty
Base: Standard Oven
BTU / Burner: 16500
Burner Configuration: Standard
Burner Style: None
Burner Type(s): None
Charbroiler Location: Full
Charbroiler Width (in): 36
Controls: Thermostatic
Depth (in): 36.75
Gas Inlet Size: 1.25
Gas Type: NG
Heat: Gas
Height (in): 36
Installation Type: Freestanding
Max Temp: 550
Number of Burners: None
Number of Ovens: Single
Product: Gas Ranges
Product Type: Cooking Equipment
Rack Positions per Standard Oven: 3
Racks per Standard Oven: 1
Range Configuration: Charbroiler
Rating: Best
Series: V Series
Standard Oven BTU/hr: 32000
Standard Oven Dimensions: 27"W x 27"D x 13"H
Total BTU: 149000
Vent: Stub Riser
Warranty: 1-year Limited Parts & Labor
Width (in): 36
Weight: 685.00
