Vulcan VTC24B 24" Gas Range W/ Charbroiler & Storage Base, Liquid Propane

The Vulcan VTC24B gas range is built with a 24-inch-wide infrared charbroiler with two 11-inch-wide by 25-inch-deep stainless steel cooking grids that leave behind appetizing grill lines when cooking steak, chicken, or vegetables. The combination of each grid's stainless steel infrared emitter panel and 22,000-BTU patented infrared burner system enables the burners to generate high heat evenly and quickly. To control incoming gas pressure, each burner includes a high-range heat control valve. Both burners' chrome control knobs deliver a sleek, upscale appearance to establish a high-end look in the back of house. To simplify cleanup between uses, the full-width stainless steel crumb tray can be removed.
For convenient storage of flour, spices, oil, cookware, and utensils, the Vulcan VTC24B commercial range's cabinet base features universal rack guides and one removable shelf. A stainless steel cabinet box conceals the base to secure stored contents in place and create a streamlined look. For uniformity, the stub back, base, sides, burner box, front top ledge, and front are also made of wear-, dent-, and rust-resistant stainless steel. This 24-inch-wide by 36 3/4-inch-deep by 36-inch-tall unit is positioned on 6-inch-tall adjustable stainless steel legs for stability on irregular surfaces.

Product Details





24-in.-wide charbroiler with (2) 11-in.-wide x 25-in.-wide stainless steel cooking grids
Heavy-duty stainless steel infrared emitter panels
(2) 22,000-BTU patented infrared burner systems
Direct ignition piezo-spark burners
Full-width stainless steel crumb tray
1 high-range heat control valve for each burner
Chrome burner knobs
Front, front top ledge, burner box, sides, base, and stub back made of durable, corrosion-resistant stainless steel
Cabinet base with universal guides, removable shelf, and hinged stainless steel door
4-in. stub riser
6-in. adjustable legs
44,000 BTU

Dimensions & Utilities





24 in. W x 36 3/4 in. D x 36 in. H
Powered by LP gas
1 1/4-in. diameter front gas manifold
1 1/4-in. rear gas connection (capped)
Specifications
Manufacturer
Vulcan

Application
Heavy Duty

Base
Storage

BTU / Burner
30000

Burner Configuration
Standard

Burner Style
None

Burner Type(s)
None

Controls
Manual

Depth (in)
36.75

Gas Type
LP

Heat
Gas

Height (in)
36

Installation Type
Freestanding

Number of Burners
None

Number of Ovens
No Oven

Product
Gas Ranges

Product Type
Cooking Equipment

Range Configuration
Charbroiler

Rating
Best

Series
VTC Series

Special Features
Spark Ignition

Total BTU
44000

Vent
Stub Back

Warranty
1-year Limited Parts & Labor

Width (in)
24

Weight
405.00

Manufacturer: Vulcan
Application: Heavy Duty
Base: Storage
BTU / Burner: 30000
Burner Configuration: Standard
Burner Style: None
Burner Type(s): None
Controls: Manual
Depth (in): 36.75
Gas Type: LP
Heat: Gas
Height (in): 36
Installation Type: Freestanding
Number of Burners: None
Number of Ovens: No Oven
Product: Gas Ranges
Product Type: Cooking Equipment
Range Configuration: Charbroiler
Rating: Best
Series: VTC Series
Special Features: Spark Ignition
Total BTU: 44000
Vent: Stub Back
Warranty: 1-year Limited Parts & Labor
Width (in): 24
Weight: 405.00
