Vulcan 2ER85AF Electric Fryer - (2) 85 Lb Vats, Floor Model, 208v/3ph
Overview
Description
The Vulcan 2ER85AF electric fryer is equipped with a solid-state analog knob control system, allowing precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. Designed for high-volume commercial kitchens, this floor model fryer includes two 85-pound vats, offering a total oil capacity of 170 pounds. Multiple fat melt modes ensure gradual oil heating, while low-watt density ribbon-style heating elements enhance heat distribution and recovery for optimal frying performance.
Built with a 16-gauge stainless steel fry tank, the Vulcan 2ER85AF electric fryer provides durability and lasting performance. The 1 1/4-inch full-port ball-type drain valve allows for quick and controlled oil removal, while the drain valve interlock switch automatically turns off the heating elements when oil is drained or the elements are lifted for cleaning. The Boil-Out ByPass® system enables operators to remove boil-out solution without contact with the drain manifold, filter pan, or motor/pump. The KleenScreen PLUS® filtration system extends oil life by capturing debris, and the seamless 18-gauge stainless steel filter pan supports effective filtration. This fryer stands on four 6-inch adjustable legs for added stability and height customization.
Product Details
(2) 85-pound vats
170-lb. total oil capacity
16-ga. stainless steel fry tank
Seamless 18-ga. stainless steel filter pan
Stainless steel cabinet
Solid-state analog knob controls
Temperature range: 200-390 degrees F
Multiple fat melt modes
Fast heat recovery
KleenScreen PLUS filtration system
Boil-Out ByPass system
1 1/4-in. full-port ball-type drain valve
Drain valve interlock switch
Low-watt density ribbon-style heating elements
2 twin fry baskets with plastic-coated handles
(4) 6-inch adjustable legs
Dimensions & Utilities
42 in. W x 34 3/8 in. D x 39 7/16in. H
24 kW
208 V/60 Hz/3 ph
Product Features
Specifications
Manufacturer
Vulcan
Capacity (lbs)
85
Heat
Electric
Hertz
60
kW
17
Number of Fry Pots
2
Oil Capacity (lb)
170
Oil Capacity/Fryer (lb)
85
Phase
3
Product
Electric Fryers
Product Type
Cooking Equipment
Rating
Best
Series
2ER85 Series
Type
Floor Model
Voltage
208
Warranty
1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)
42
Weight
700.00
Specifications
Manufacturer: Vulcan
Capacity (lbs): 85
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 2
Oil Capacity (lb): 170
Oil Capacity/Fryer (lb): 85
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 2ER85 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 42
Weight: 700.00
