Vulcan 3ER50AF Electric Fryer - (3) 50 Lb Vats, Floor Model, 208v/3ph
Overview
Description
Made with a 16-gauge stainless steel fry tank, the Vulcan 3ER50AF electric fryer provides lasting durability in commercial kitchens. This floor model fryer features three 50-pound vats, offering a total oil capacity of 150 pounds for high-volume frying operations. The solid-state analog knob control allows precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. Multiple fat melt modes support controlled oil heating, while the low-watt density ribbon-style heating elements provide fast heat recovery and energy efficiency.
Designed for effective oil filtration, the Vulcan 3ER50AF fryer includes an 18-gauge stainless steel filter pan with a 70-pound frying compound capacity. The KleenScreen PLUS® filtration system captures food debris, extending oil life and reducing waste. A 1 1/4-inch full-port ball-type drain valve facilitates controlled oil removal, while the drain valve interlock switch automatically turns off heating elements when oil is drained or the elements are lifted for cleaning. The Boil-Out ByPass® system enables operators to remove boil-out solution without contact with the drain manifold, filter pan, or motor/pump. The fryer is supported by four 6-inch adjustable legs for stability and height customization.
Product Details
(3) 50-pound vats
150-pound total oil capacity
Solid-state analog knob control
Temperature range: 200-390 degrees F
Multiple fat melt modes
Fast heat recovery
KleenScreen PLUS filtration system
Boil-Out ByPass system
1 1/4-in. full-port ball-type drain valve
Drain valve interlock switch
Low-watt density ribbon-style heating elements
16-ga. stainless steel fry tank
Seamless 18-ga. stainless steel filter pan
Stainless steel cabinet
2 twin fry baskets with plastic-coated handles
(4) 6-inch adjustable legs
Dimensions & Utilities
46 1/2 in. W x 34 3/8 in. D x 36 1/4 in. H
17 kW
208 V/60 Hz/3 ph
Product Features
Specifications
Manufacturer
Vulcan
Capacity (lbs)
50
Heat
Electric
Hertz
60
kW
17
Number of Fry Pots
3
Oil Capacity (lb)
150
Oil Capacity/Fryer (lb)
50
Phase
3
Product
Electric Fryers
Product Type
Cooking Equipment
Rating
Best
Series
3ER50 Series
Type
Floor Model
Voltage
208
Warranty
1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)
46.5
Weight
717.00
Specifications
Manufacturer: Vulcan
Capacity (lbs): 50
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3ER50 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
