Vulcan 3ER85CF Electric Fryer - (3) 85 Lb Vats, Floor Model, 208v/3ph

The Vulcan 3ER85CF electric fryer is built with a 16-gauge stainless steel fry tank, providing durability for high-volume commercial kitchens. This floor model fryer features three 85-pound vats, offering a total oil capacity of 255 pounds to accommodate large frying operations. The Boil-Out ByPass® system allows boil-out solution to be removed without contact with the drain manifold, filter pan, or motor/pump. Ten programmable product keys and ten countdown timers simplify cooking management, while multiple fat melt modes enhance efficiency during operation.
Designed for easy oil management, the Vulcan 3ER85CF fryer includes a 1 1/4-inch full-port ball-type drain valve for quick and controlled oil removal. The drain valve interlock switch automatically shuts off heating elements when oil is drained or the elements are lifted for cleaning. The programmable computer control system ensures precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. The 18-gauge stainless steel filter pan supports the KleenScreen PLUS® filtration system, which extends oil life by capturing food debris.

Product Details





(3) 85-lb. vats
255-pound total oil capacity
Programmable computer control system
Temperature range: 200-390 degrees F
10 programmable product keys
10 countdown timers
Multiple fat melt modes
Boil-Out ByPass system
KleenScreen PLUS filtration system
1 1/4-in. full-port ball-type drain valve
Drain valve interlock switch
Low-watt density ribbon-style heating elements
16-ga. stainless steel fry tank
Seamless 18-ga. stainless steel filter pan
Stainless steel cabinet
2 twin fry baskets with plastic-coated handles
(4) 6-in. adjustable legs

Dimensions & Utilities





Overall: 63 in. W x 34 3/8 in. D x 39 7/16 in. H
24 kW
208 V/60 Hz/3 ph

Product Features
Specifications
Manufacturer
Vulcan

Capacity (lbs)
85

Heat
Electric

Hertz
60

kW
17

Number of Fry Pots
3

Oil Capacity (lb)
255

Oil Capacity/Fryer (lb)
85

Phase
3

Product
Electric Fryers

Product Type
Cooking Equipment

Rating
Best

Series
3ER85 Series

Type
Floor Model

Voltage
208

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
968.00

Manufacturer: Vulcan
Capacity (lbs): 85
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 3
Oil Capacity (lb): 255
Oil Capacity/Fryer (lb): 85
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3ER85 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
