Vulcan 3ER85AF Electric Fryer - (3) 85 Lb Vats, Floor Model, 208v/3ph

the Vulcan 3ER85AF electric fryer is designed with a solid-state analog knob control system, providing precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. This floor model fryer includes three 85-pound vats, offering a total oil capacity of 255 pounds to support high-volume frying operations. Multiple fat melt modes ensure controlled oil heating, while the low-watt density ribbon-style heating elements enhance heat recovery for efficient cooking.
For simplified oil management, the Vulcan 3ER85AF fryer features a 1 1/4-inch full-port ball-type drain valve for controlled oil removal. The drain valve interlock switch automatically shuts off heating elements when draining oil or lifting elements during cleaning. The Boil-Out ByPass® system allows boil-out solution to be removed without contact with the drain manifold, filter pan, or motor/pump. The seamless 18-gauge stainless steel filter pan supports the KleenScreen PLUS® filtration system, which extends oil life by capturing food debris. The fryer stands on four 6-inch adjustable legs for stability and height customization.

Product Details





(3) 85-pound vats
255-pound total oil capacity
16-ga. stainless steel fry tank
18-ga. stainless steel filter pan
Stainless steel cabinet
Solid-state analog knob control
Temperature range: 200-390 degrees F
Multiple fat melt modes
KleenScreen PLUS filtration system
Boil-Out ByPass system
1 1/4-in. full-port ball-type drain valve
Drain valve interlock switch
Low-watt density ribbon-style heating elements
2 twin fry baskets with plastic-coated handles
(4) 6-inch adjustable legs

Dimensions & Utilities





63 in. W x 34 3/8 in. D x 39 7/16 in. H
24 kW
208 V/60 Hz/3 ph

Product Features
Specifications
Manufacturer
Vulcan

Capacity (lbs)
85

Heat
Electric

Hertz
60

kW
17

Number of Fry Pots
3

Oil Capacity (lb)
255

Oil Capacity/Fryer (lb)
85

Phase
3

Product
Electric Fryers

Product Type
Cooking Equipment

Rating
Best

Series
3ER85 Series

Type
Floor Model

Voltage
208

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
968.00

Manufacturer: Vulcan
Capacity (lbs): 85
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 3
Oil Capacity (lb): 255
Oil Capacity/Fryer (lb): 85
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3ER85 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
