Vulcan 3ER85DF Electric Fryer - (3) 85 Lb Vats, Floor Model, 208v/3ph
Overview
Description
The Vulcan 3ER85DF electric fryer is designed with solid-state digital temperature controls, ensuring precise adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. This floor model fryer includes three 85-pound vats, providing a total oil capacity of 255 pounds to accommodate high-volume frying operations. Multiple fat melt modes support controlled oil heating, while the low-watt density ribbon-style heating elements enhance heat recovery for consistent cooking performance. The unit also features two countdown timers and a boil-out mode for simplified maintenance.
Built with a 16-gauge stainless steel fry tank, the Vulcan 3ER85DF electric fryer offers durability in demanding commercial kitchens. A 1 1/4-inch full-port ball-type drain valve ensures smooth oil removal, while the drain valve interlock switch (DVI) automatically shuts off heating elements when oil is drained or the elements are lifted during cleaning. The seamless 18-gauge stainless steel filter pan supports the KleenScreen PLUS® filtration system, which extends oil life by capturing food debris. The fryer stands on four 6-inch adjustable legs for stability and height adjustment. Twin fry baskets with plastic-coated handles are included for safe handling.
Product Details
(3) 85-lb. vats
255-lb. total oil capacity
16-ga. stainless steel fry tank
Seamless 18-ga. stainless steel filter pan
Stainless steel cabinet
Solid-state digital temperature controls
Temperature range: 200-390 degrees F
Multiple fat melt modes
Fast heat recovery
2 countdown timers
KleenScreen PLUS filtration system
Boil-Out ByPass system
1 1/4-in. full-port ball-type drain valve
Drain valve interlock switch (DVI)
Low-watt density ribbon-style heating elements
2 twin fry baskets with plastic-coated handles
(4) 6-in. adjustable legs
Dimensions & Utilities
63 in. W x 34 3/8 in. D x 39 7/16 in. H
24 kW
208 V/60 Hz/3 ph
Product Features
Specifications
Manufacturer
Vulcan
Capacity (lbs)
85
Heat
Electric
Hertz
60
kW
17
Number of Fry Pots
3
Oil Capacity (lb)
255
Oil Capacity/Fryer (lb)
85
Phase
3
Product
Electric Fryers
Product Type
Cooking Equipment
Rating
Best
Series
3ER85 Series
Type
Floor Model
Voltage
208
Warranty
1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)
63
Weight
968.00
Specifications
Manufacturer: Vulcan
Capacity (lbs): 85
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 3
Oil Capacity (lb): 255
Oil Capacity/Fryer (lb): 85
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3ER85 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
