Vulcan 4ER50AF Electric Fryer - (4) 50 Lb Vats, Floor Model, 208v/3ph
Overview
Description
The Vulcan 4ER50AF electric fryer features a solid-state analog knob control system, providing precise temperature adjustments from 200 to 390 degrees Fahrenheit within +/- 2 degrees. This floor model fryer includes four, 50-pound vats, offering a total oil capacity of 200 pounds to support high-volume frying applications. Multiple fat melt modes ensure controlled oil heating, while the low-watt density ribbon-style heating elements improve heat recovery. The KleenScreen PLUS® filtration system helps extend oil life by removing food debris, reducing operating costs.
Constructed with a durable 16-gauge stainless steel fry tank, the Vulcan 4ER50AF electric fryer is designed for longevity in demanding commercial kitchens. A 1 1/4-inch full-port ball-type drain valve enables controlled oil removal, and the Drain Valve Interlock Switch (DVI) automatically shuts off heating elements when oil is drained or the elements are lifted during cleaning. The 18-gauge stainless steel filter pan holds up to 70 pounds of frying compound, while the Boil-Out ByPass® system simplifies cleaning without contact with the drain manifold, filter pan, or pump. The fryer stands on four 6-inch adjustable legs for stability and height adjustment.
Product Details
4ER50 series
(4) 50-lb. vats
200-lb. total oil capacity
18-gauge stainless steel filter pan
Stainless steel cabinet
Solid-state analog knob control
Temperature holding range: 200-390 degrees F
Multiple fat melt modes
Fast heat recovery
KleenScreen PLUS filtration system
Boil-Out ByPass system
1 1/4-in. full-port ball-type drain valve
Drain Valve Interlock Switch (DVI)
Low-watt density ribbon-style heating elements
16-gauge stainless steel fry tank
2 twin fry baskets with plastic-coated handles
(4) 6-in. adjustable legs
Dimensions & Utilities
Overall dimensions: 62 in. W x 34 19/50 in. D x 36 1/4 in. H
17 kW
208 V/60 Hz/3 ph
Product Features
Specifications
Manufacturer
Vulcan
Capacity (lbs)
50
Heat
Electric
Hertz
60
kW
17
Number of Fry Pots
4
Oil Capacity (lb)
200
Oil Capacity/Fryer (lb)
50
Phase
3
Product
Electric Fryers
Product Type
Cooking Equipment
Rating
Best
Series
4ER50 Series
Type
Floor Model
Voltage
208
Warranty
1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)
62
Weight
927.00
Specifications
Manufacturer: Vulcan
Capacity (lbs): 50
Heat: Electric
Hertz: 60
kW: 17
Number of Fry Pots: 4
Oil Capacity (lb): 200
Oil Capacity/Fryer (lb): 50
Phase: 3
Product: Electric Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 4ER50 Series
Type: Floor Model
Voltage: 208
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 62
Weight: 927.00
