Vulcan 3GR45MF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

Designed with three batteries, the Vulcan 3GR45MF gas fryer's vats each accommodate 45 to 50 pounds of oila€”great for frying breaded fish, chicken tenders, and fries in high-volume establishments. Its four heat exchanger tubes spread heat evenly throughout the oil; because it has a large heat transfer area, it's energy efficient. The durable stainless steel cabinet and tank endure rigorous use, while its twin fry baskets reduce user burns with plastic-coated handles. To collect loose sediment so it doesn't burn, the cold zone boasts a V-shaped design. This floor model's millivolt thermostat sets temperatures between 200 and 400 degrees Fahrenheit. It includes a tank brush, stainless steel crumb scoop, and a clean-out rod to streamline cleaning. It also sits on four 6-inch casters that ease mobility for maintenance and cleaning; two of these casters lock for stationary placement.
To reducet fire risks, the Vulcan 3GR45MF deep fryer has a hi-limit shut off that turns off the gas burners when oil reaches extreme temperatures. It operates with liquid propane, outputs 360,000 BTUs per hour, and features a combination gas shut-off valve and pilot safety system for enhanced safety. Operators can prolong the oil's life with the Kleenscreen Plus® filtration system, which filters oil through its 270-square-inch stainless steel mesh screen and recirculates it to be reused with minimal flavor transfer. The 18-gauge stainless steel filter pan weighs 20 1/2 pounds, is built with lift handles, and sits on drawer slides for simple handling. Its 1 1/4-inch ball-type drain valve includes an interlock switch that automatically powers off the gas burners when the valve is draining oil. For simplified tank cleaning, its Boil Out ByPass® the system enables employees to boil water and cleaning solution in the vat and then remove the liquids without interfering with other fryer parts; the pan and screen are also dishwasher safe.

Product Details





Part of the GR series
45- to 50-lb. capacity per vat
3 batteries
Floor model
Stainless steel cabinet and tank
4 heat exchanger tubes
V-shaped cold zone
1 1/4-in. full-port, ball-type drain valve
Twin fry basket with plastic-coated handles
Millivolt thermostat control temperature range: 200 to 400 degrees F
Includes tank brush, stainless steel crumb scoop, and clean-out rod
(4) 6-in. casters (2 locking)
Hi-limit shut off
360,000 BTU
Combination gas shut-off valve and pilot safety system

Kleenscreen Plus Filtration System





Drain valve interlock switch automatically turns off gas burners if drain valve is opened
20 1/2-lb. seamless filter pan made of 18-ga. stainless steel
270-sq-in. stainless steel mesh filter screen is double sided
Boil Out ByPass removes boil-out solution from vat
Dishwasher-safe filter pan and screen
Pan has lift handles and is placed on drawer slides
70-lb. frying compound capacity 2. Motor and pump circulate oil at 8 gallons per minute

One-touch push-button switch activates filter pump controls
High-temperature discard hose

Dimensions & Utilities





Overall: 46 1/2 in. W x 30 1/8 in. D x 46 1/4 in. H
LP gas
6 A, 1/3 HP
120 V/60 Hz/1 ph, includes cord with NEMA 5-15P plug
1/2-in. ID and 3/4-in. OD rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
120000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
3GR45M Series

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
695.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 120000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3GR45M Series
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 695.00
