Vulcan 3GR65MF Gas Fryer - (3) 70 Lb Vats, Floor Model, Natural Gas

For cooking breaded fish, chicken, and other meats, the Vulcan 3GR65MF gas fryer operates in a battery system design that features three total 70-pound-capacity vats. This unit boasts a temperature range from 200 to 400 degrees Fahrenheit and is operated with millivolt thermostat controls. To assist with high-volume production without sacrificing quality, its five heat tubes provide even heat exchange.
To maintain oil conditions after back-to-back frying and reduce premature refilling, it integrates a KleenScreen PLUS® filtration system that circulates frying compound at 8 gallons per minute once activated via its one-touch push button. This system's Boil Out ByPass® removes boil-out solution from the fry tanks without contacting the drain manifold, motor, pump, or filter pan. Designed for efficient filtering, its stainless steel mesh screen filters from two sides.
Overall, the Vulcan 3GR65MF floor model gas fryer measures 63 inches wide by 30 1/8 inches deep by 46 1/4 inches high. This heavy-duty unit's 19 1/4-inch-wide by 14-inch-deep fry tank and cabinet are constructed of stainless steel, which makes it ideal for withstanding heavy-grease kitchens. To aid in cleaning processes, operators can utilize Its 1 1/4-inch full port ball type drain valve, tank brush, stainless steel crumb scoop, and clean-out rod.

Product Details





Part of the 3GR65M series
3 fry pots
Capacity per fryer vat: 65-70 lb. (195-210 lb. total)
Twin baskets feature plastic-coated handles
(4) 6-in. adjustable casters
36 1/4-in. working height
Stainless steel cabinet and fry tank
Includes tank brush, stainless steel crumb scoop, and clean-out rod
1 1/4-in. full port ball type drain valve

Heat System Details





Millivolt thermostat controls
Temperature range: 200-400 degrees F
Hi-limit shutoff
Combination gas shut-off valve and pilot system

KleenScreen PLUS® Filtration System Details





Motor and pump circulate compound at 8 gal. per minute
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
Boil Out ByPass function
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/4 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 46 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
450,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
150000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
3GR65M Series

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
904.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 150000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3GR65M Series
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 904.00
