Vulcan 3GR85MF Gas Fryer - (3) 90 Lb Vats, Floor Model, Liquid Propane

Because the Vulcan 3GR85MF gas fryer features integrated millivolt controls behind the door, it's simple to operate, which minimizes necessary staff training. Furthermore, it sits on four 6-inch casters, so it can be easily installed and maneuvered for cleaning and maintenance. This unit measures 63 inches wide by 34 3/8 inches deep by 46 1/4 inches high and is constructed of stainless steel to match other kitchen equipment while avoiding dents and scratches. To ease cleaning, this fry tank includes a 1 1/4-inch full port ball type drain valve, tank brush, and clean-out rod.
The Vulcan 3GR85MF commercial gas fryer features three 90-pound-capacity vats to promote high-volume production of fries, mozzarella sticks, and hushpuppies or breaded chicken, fish, pork loin, and other meats. To ease retrieval and removal of cooked products, its 19 1/2-inch-wide by 18 1/4-inch-deep fry tanks each hold two twin baskets that feature plastic-coated handles to reduce heat transfer to palms. This unit maintains temperatures between 200 and 400 degrees Fahrenheit and can extend oil life with its KleenScreen Plus® filtration feature. This filtration system works across the three-fryer battery system and has a Boil Out ByPass® that effectively removes boil-out solution from the tanks without contacting the drain manifold, motor, or filter pan. The filter's stainless steel mesh screen filters from both sides, while its motor circulates oil at 8 gallons per minute.

Product Details





Part of the 3GR85M series
3 fry pots
Capacity per fry pot: 85-90 lb. (255-270 lb. total)
Stainless steel cabinet and fry tank
Twin baskets feature plastic-coated handles
(4) 6-in. adjustable casters
Includes tank brush and clean-out rod

Heat System Details





Millivolt thermostat controls
Temperature range: 200-400 degrees F
Hi-limit shutoff
Combination gas shut-off valve and pilot system for user safety

Filtration Details





KleenScreen PLUS filtration system
Boil-out ByPass
Motor and pump circulate compound at 8 gal. per minute
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 8 3/4 in. W x 16 3/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 18 1/4 in. D
Overall: 63 in. W x 34 3/8 in. D x 46 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
450,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
150000

Capacity (lbs)
270

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
270

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
3GR85M Series

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
922.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 150000
Capacity (lbs): 270
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 270
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: 3GR85M Series
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 922.00
