Vulcan 3TR45AF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR45AF gas fryer maintains temperatures between 200 and 390 degrees Fahrenheit, which can be adjusted with the integrated solid-state analog controls. This three-battery fryer unit holds 45-50 pounds of oil per vat and features user-selectable fat melt modes to accommodate different types of shortening. Its SoftStart® matchless ignition produces only 105,000 BTU during startup to prevent scorching while efficiently heating the oil. For additional energy conservation, its ThreePass® heat transfer system yields 60.9 percent cooking efficiency and 72 percent thermal efficiency. To promote operator safety, each vat features two 6 1/2-inch-wide by 13 1/4-inch-deep by 6-inch-high fry baskets with plastic-coated handles to reduce heat transfer.
Overall, the Vulcan 3TR45AF fryer measures 46 1/2 inches wide by 30 1/4 inches deep by 47 1/4 inches high. Its cabinet and fry tank are constructed of stainless steel, which is a durable and corrosion-resistant metal capable of withstanding heavy-grease settings. For efficient oil circulation, it includes a 1 1/4-inch port ball type drain valve and an 18-gauge stainless steel filter pan. To clean exterior or interior parts, operators can utilize its included tank brush and clean-out rod, and to reduce necessary labor, its KleenScreen PLUS® technology filters oil through two sides of a stainless steel filtration screena€”extending oil life and preventing flavor transfer.

Product Details





Part of the PowerFry3® series
3 fry pots
Capacity per fryer: 45-50 lb. (135-150 lb. total)
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters

Heat System Details





Temperature range: 200-390 degrees F
Solid-state analog controls
Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
User-adjustable melt cycles
ThreePass heat transfer system
SoftStart electronic ignition system

Filtration System Details





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
210,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
