Vulcan 3TR45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

The Vulcan 3TR45CF gas fryer features three total vats that hold 45 to 50 pounds of oil each. Part of the PowerFry3® series, this unit features programmable controls that assist operators with adjusting temperatures between 200 and 390 degrees Fahrenheit. Its SoftStart® heat transfer system prevents scorching and conserves energy by lowering output to 105,000 BTU per hour during startup, while its ThreePass® heat transfer system yields 60 percent cooking efficiency and 72 percent thermal efficiency. To drop and retrieve breaded foods, each vat has twin baskets with plastic-coated handles.
Equipped with KleenScreen PLUS® technology, the Vulcan 3TR45CF gas fryer offers adept filtration that extends oil life by 200 to 400 percent. This system's 1/3-horsepower motor circulates oil at 8 gallons per minute through both sides of a stainless steel filtration screen to remove sediment and small particulate that could affect oil life and taste. When oil needs to be replaced, it can be drained through the 1 1/4-inch port ball type drain valve into the 18-gauge stainless steel filter pan. Overall, this unit measures 46 1/2 inches wide by 30 1/8-inches-deep by 47 1/4 inches high and its cabinet and fry tank are constructed of stainless steel to reduce marring to the structure. It sits on a set of four 6-inch casters to ease maneuvering for cleaning or maintenance.

Product Details





Part of the PowerFry3® series
3-fryer battery
Total capacity: 135-150 lb. (45-50 lb. per fryer)
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees F
Programmable computer controls with melt cycles
ThreePass heat transfer system
Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
SoftStart electronic ignition system

Filtration System Details





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
210,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
