Vulcan 3TR45AF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane
Overview
Description
Because the Vulcan 3TR45AF fryer is a three-battery unit, each vat holds 45 to 50 pounds of oil. Its KleenScreen PLUS® filtration system utilizes a 1/3-horsepower motor that circulates oil at 8 gallons per minute. After high-intensity use, its integrated 18-gauge stainless steel filter pan and 1 1/4-inch port ball type drain valve help empty oil when it needs replaced. During cooking, this unit maintains temperatures between 200 and 390 degrees Fahrenheit and can be adjusted with solid-state analog controls. To produce quality products at high volumes, it integrates a ThreePass® heat transfer system for even heating and a SoftStart® electronic ignition that prevents scorching and conserves energy by lowering output to 105,000 BTU per hour during startup.
Overall, the Vulcan 3TR45AF gas fryer outputs 210,000 BTU per hour and measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high. For use in intense back-line kitchens, it has a stainless steel 14-inch-wide by 14-inch-deep fry tank and cabinet. Great for withstanding greasy settings, it includes a tank brush and clean-out rod to assit operators with cleaning. To ease maneuvering for cleaning or maintenance, it sits on four 6-inch casters.
Product Details
Part of the PowerFry3® series
3-fryer battery system
Capacity per fry pot: 45-50 lb.
Total capacity: 135-150 lb.
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters
Heat System Details
Temperature range: 200-390 degrees F
Solid-state analog controls
User-selectable fat melt modes
Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
ThreePass heat transfer system
SoftStart electronic ignition system
Filtration System Details
KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch
Dimensions & Utilities
Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
210,000 BTU
Product Features
Specifications
Manufacturer
Vulcan
Baskets
2
BTU per Fryer
70000
Capacity (lbs)
150
Food Type
Breaded
Frypot Style
Tube Type
Gas Type
LP
Heat
Gas
NEMA
5-15P
Number of Fry Pots
3
Oil Capacity (lb)
150
Oil Capacity/Fryer (lb)
50
Product
Gas Fryers
Product Type
Cooking Equipment
Rating
Best
Series
PowerFry3®
Special Features
Casters Included - Uninstalled
Type
Floor Model
Warranty
1-year Limited Parts & Labor; 10-year Fry Tank
Width (in)
46.5
Weight
717.00
Specifications
Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
