Vulcan 3TR45DF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

The Vulcan 3TR45DF gas fryer has three fry pots with 45- to 50-pound oil capacities. This unit features a three-battery configuration, meaning each fryer shares a gas connection and filtration system. It's powered by liquid propane, which heats faster than natural gas alternatives. To preserve oil quality, its KleenScreen PLUS® filtration system features a 1/3-horsepower motor with a stainless steel mesh screen that filters oil from two sides to remove small particulate and sediment. Its temperature can be adjusted between 200 and 390 degrees Fahrenheit with its solid-state controls, and for accurate monitoring, it features a digital read-out display. To conserve energy, this fryer's SoftStart&trade electronic ignition reduces output to 105,000 BTU per hour during startup, and it features a ThreePass® heat transfer system that yields 72 percent thermal efficiency with 60.9 percent cooking efficiency.
Overall, the Vulcan 3TR45DF floor model fryer measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high. The cabinet and fry tank are constructed of stainless steel, which means it's durable and minimizes irregularities to the structure. For accuracy, this unit includes two countdown timers that can track actual or compensating time to account for temperature fluctuations. To assist employees with dropping and removing breaded chicken and fish or mozzarella sticks and fries, each vat comes with twin baskets that have plastic-coated handles to minimize heat transfer to employees' palms. When oil needs to be discarded, its 1 1/4-inch port ball type drain valve facilitates emptying , while its tank brush, auto boil-out mode, and clean-out rod assist with cleaning. To ease maneuvering, it's mounted on four 6-inch casters.

Product Details





Part of the PowerFry3® series
3-battery frying system
Capacity per fryer: 45-50 lb. (135-150 lb. total)
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees F
Solid-state digital controls
3 melt modes for different fat types
2 countdown timers can show compensating or actual time
Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
ThreePass heat transfer system
SoftStart electronic ignition system
Hi-limit shut off

KleenScreen PLUS Filtration Details





18-ga. stainless steel filter pan
Stainless steel mesh screen
Circulates 8 gallons of oil per minute
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
210,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
