Vulcan 3TR45DF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR45DF gas fryer measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high and sits on a set of four 6-inch casters. It features three 14-inch-wide by 14-inch-deep fry tanks and cabinets made of stainless steel to withstand aggressive settings with enhanced durability and corrosion resistance. This three-battery unit's vats each hold 45 to 50 pounds of oil.
This unit maintains even heating with its ThreePass® heat transfer system, which yields 72 percent thermal efficiency and 60.9 percent cooking efficiency. It outputs 210,000 BTU total, but its SoftStart® electronic ignition lowers output to 105,000 BTU per hour during startup to conserve energy and prevent scorching. To increase oil life, its KleenScreen PLUS® filtration system circulates oil at 8 gallons per minute through its stainless steel mesh screen. For employee safety, its interlock switch turns off the gas burners while filtering the oil.
With its digital controls, operators can adjust temperatures from 200 to 390 degrees Fahrenheit. To streamline cleaning, the Vulcan 3TR45DF gas fryer features a 1 1/4-inch port ball type drain valve for emptying oil quickly and without hassle. For efficient cleaning after use, it includes a tank brush, auto boil-out mode, and clean-out rod.

Product Details





Part of the PowerFry3® series
3 fry pots
Fry pot capacity: 45-50 lb. (135-150 lb. total)
(4) 6-in. adjustable casters
Stainless steel cabinet and fry tank
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees F
Solid-state digital control
2 countdown timers can track compensating or actual time to account for temperature fluctuations
3 melt modes for different shortening types
Outputs 4,318 BTU/hr. when idle to maintain cooking temperatures
ThreePass heat transfer system
Twin baskets feature plastic-coated handles
SoftStart electric ignition system

Integrated Filtration System





KleenScreen PLUS filtration
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
Auto boil-out mode
Drain valve interlock switch
1 1/4-in. port ball type drain valve

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
210,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
