Vulcan 3TR45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR45CF gas fryer's temperature can be adjusted between 200 and 390 degrees Fahrenheit with its programmable computer controls; for operator convenience, these digital controls can also save 10 menu timers and display product name and cook times. This unit outputs 210,000 BTU per hour, but its SoftStart® electronic ignition lowers output to 105,000 BTU per hour during startup to prevent scorching. Its 14-inch-wide by 14-inch-deep fry tanks are heated with its ThreePass&trade heat transfer system which yields 60.9 percent cooking efficiency and 72 percent thermal efficiency. To adapt to a variety of culinary needs, its three fat melt modes can accommodate different shortening types. For an extended oil life, its KleenScreen PLUS® filtration system features a 1/3-horsepower motor that circulates 8 gallons of oil per minute through its stainless steel mesh screen to remove sediment and small particulate.
Overall, the Vulcan 3TR45CF fryer measures 46 1/2 inches wide by 30 1/2 inches deep by 47 1/8 inches high and features three 45- to 50-pound-capacity fry vats. Its fry tank and cabinet are constructed of stainless to withstand intense settings and resist corrosion. This unit includes two twin fry baskets to simplify the insertion or removal of breaded foods, and because they feature plastic-coated handles, they minimize operator burn risks. To assist with cleaning, its 1 1/4-inch port ball type drain valve facilitates oil removal, and it ships with a tank brush and clean-out rod. To maneuver this heavy-duty unit for maintenance or cleaning, it's mounted on a set of four 6-inch castersa€”two of which lock for stability.

Product Details





Part of the PowerFry3® series
Oil capacity: 45-50 lb. per fryer (135-150 lb. total)
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees F
Programmable computer controls with 3 melt modes
10 menu timers with digital display
Offline programming available through USB (software included)
Can cook with compensating or actual time
ThreePass heat transfer system
Outputs just 4,318 BTU/hr. when idle to maintain cooking temperatures
SoftStart electronic ignition system

Filtration System Details





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel mesh filter screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 46 1/2 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
210,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
