Vulcan 3TR65CF Gas Fryer - (3) 70 Lb Vats, Floor Model, Liquid Propane

For consistency in busy kitchens, the Vulcan 3TR65CF gas fryer features ten programmable menu timers that can be uploaded through a USB interface (software included). Once installed, its digital display can show product names and menu timers, and its temperature can be adjusted between 200 and 390 degrees Fahrenheit. To prevent scorching while conserving energy, its SoftStart® electronic ignition system lowers output to 120,000 BTU per hour during startup, while it's idle temperature setting uses only 5,083 BTU per hour to maintain cooking temperatures.
This fryer's KleenScreen PLUS® filtration system circulates 8 gallons of oil per minute to preserve oil quality and prevent premature refilling. Its stainless steel mesh screen filters oil through both sides to sift out sediment and particulate, and when oil does need replaced, its 1 1/4-inch port ball type drain valve assists with oil removal. To simplify operation, this system's 1/3-horsepower motor and pump are activated with a one-touch push button.
Overall, the Vulcan 3TR65CF gas fryer measures 63 inches wide by 30 1/8 inches deep by 47 1/4 inches high. Its fry tank and cabinet are constructed of stainless steel, which fortifies its structure and reduces corrosion. To simplify cleaning, it has an auto boil-out mode and includes a tank brush and clean-out rod. This heavy-duty unit sits on a set of four 6-inch casters, which eases maneuvering on smooth or irregular floors.

Product Details





Part of the PowerFry3® series
3 fry pots
Total capacity: 195-210 lb. (65-70 lb. per fry pot)
Outputs just 5,083 BTU when idle
ThreePass® heat transfer system
Twin baskets with plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters

Computer controls





10 programmable menu timers and three melt modes
Digital display of product name and menu items
Offline USB programming
Adjustable temperature range: 200-390 degrees F
SoftStart electronic ignition

Built-in Filtration System





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP powered
240,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
