Vulcan 3TR65AF Gas Fryer - (3) 70 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR65AF gas fryer is powered by natural gas to create temperatures between 200 and 390 degrees Fahrenheit. This temperature can be adjusted with its solid-state analog control knobs to simplify operation, while its 9 1/4-inch-wide by 13 1/4-inch-deep by 6-inch-high twin fry baskets ease dropping and removing breaded foods and feature plastic-coated handles to reduce burn ricks. This three-battery unit holds 65 to 70 pounds of oil per vat and is heated with its ThreePass® heat transfer system which yields 72 percent thermal efficiency and 60.9 percent cooking efficiency.
With its KleenScreen PLUS® filtration, this unit maintains oil conditions to minimize premature refilling. This system's 1/3-horsepower motor circulates frying compound at 8 gallons per minute through its stainless steel mesh screen to remove sediment and particulate. For uncomplicated operation, filtrations is activated with a one-touch button, and when oil does need replaced, it can be emptied through the 1 1/4-inch port ball type drain valve oil.
Overall, the Vulcan 3TR65AF fryer measures 63 inches wide by 30 1/8 inches deep by 47 1/4 inches high and outputs 210,000 BTU. However, its SoftStart® electronic ignition reduces output to 105,000 BTU during startup to prevent scorching and conserve energy, while its idle mode uses only 5,083 BTU per hour to preserve cooking temperatures. Its cabinet and fry tank are made of stainless steel, so it's durable and resistant to corrosion. It's mounted on a set of four 6-inch casters to ease transport, and to simplify cleaning operators can use the included tank brush and clean-out rod.

Product Details





Part of the PowerFry3® series
3-fryer battery
Total capacity: 195-210 lb. (65-70 lb. per fryer)
ThreePass heat transfer system
Twin baskets with plastic-coated handles
Stainless steel cabinet and fry tank
Outputs 5,083 BTU/hr. when idle
(4) 6-in. adjustable casters

Built-in Filtration System





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
Drain valve interlock switch
1 1/4-in. port ball type drain valve

Solid-state Controls





Knob controls behind doors
Temperature control: 200-390 degrees F
User-selectable fat melt modes
SoftStart matchless ignition system

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
240,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
