Vulcan 3TR65CF Gas Fryer - (3) 70 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR65CF gas fryer is a three-battery unit that holds 70 pounds of oil per vat. To maintain optimal oil conditions for high-volume production, its integrated KleenScreen PLUS® filtration circulates frying compound at 8 gallons per minute through both sides of the stainless steel mesh screen. Used oil can be emptied through the 1 1/4-inch drain valve.
This gas fryer's temperature can be adjusted between 200 and 390 degrees Fahrenheit using the computer controls. These controls can store ten menu timers that are programmable through an offline interface. So operators can differentiate between settings, this fryer has a digital character display. While this unit outputs 240,000 BTU per hour total, its SoftStart® electronic ignition system lowers output to 120,000 BTU per hour during startup to preserve oil quality and conserve energy; when idle, it needs just 5,083 BTU per hour to maintain cooking temperatures. For even heating, its ThreePass® heat transfer system yields 60.9 percent cooking efficiency and 72 percent thermal efficiency.
Overall, the Vulcan 3TR65CF gas fryer measures 63 inches wide by 30 1/8 inches deep by 47 1/4 inches high. Its fry tank and cabinet are constructed of stainless steel to withstand intense kitchen settings. It ships with a tank brush, clean-out rod, and 9 1/4-inch-wide by 13 1/4-inch-deep by 6-inch-high twin fry baskets with plastic-coated handles. This heavy-duty fryer is mounted on 6-inch casters.

Product Details





Part of the PowerFry3® series
Battery system with 3 fryers
Total unit capacity: 195-210 lb. (65-70 lb. per fryer)
ThreePass heat transfer system
Maintains cooking temperatures with just 5,083 BTU per hour when idle
Twin baskets with plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. adjustable casters

Computer Controls





10 programmable menu timers
3 melt modes for accommodating different fat types
Digital display of product name and menu items
Offline USB programming (software included)
Adjustable temperature range: 200-390 degrees F
Can cook with compensating time or actual time
SoftStart electric ignition

Built-in Filtration System





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 47 1/8 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
240,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
