Vulcan 3TR65DF Gas Fryer - (3) 70 Lb Vats, Floor Model, Liquid Propane

With an integrated KleenScreen PLUS® filtration system, the Vulcan 3TR65DF gas fryer prevents premature oil replacement. When activated with its one-touch push button, this filtration system circulates 8 gallons of hot frying compound per minute through a stainless steel mesh screen to remove particulate that could affect oil taste. This fryer can produce temperatures between 200 and 390 degrees Fahrenheit and is adjusted with solid-state digital controls. Its two countdown timers can monitor actual or compensating time to account for temperature fluctuations, and for even heating, its ThreePass® heat transfer system yields 60 percent cooking efficiency and 72 percent thermal efficiency. This system outputs 240,000 BTU total, but with its SoftStart® electronic ignition, it conserves energy by outputting only 120,000 BTU per hour. When idle, each vat requires just 5,083 BTU per hour to maintain cooking temperatures.
Overall, the Vulcan 3TR65DF gas fryer measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/4 inches high. Its cabinet and fry tank are constructed of stainless steel to fortify its structure, and because each vat measures 19 1/2 inches wide by 14 inches deep, they can hold the included twin baskets to ease cooking. This unit includes a 1 1/4-inch ball type drain valve to remove used oil, and for cleaning, it has a tank brush and clean-out rod. Because this heavy-duty fryer sits on 6-inch adjustable casters, it can be maneuvered with little difficulty.

Product Details





Part of the PowerFry3® series
3 fry pots
Capacity per frypot: 65-70 lb.
Total capacity: 195-210 lb.
Stainless steel cabinet and fry tank
Twin baskets feature plastic-coated handles
Uses 5,083 BTU per hour when idle
(4) 6-in. adjustable casters
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees F
Solid-state digital control with melt cycles
2 countdown timers
ThreePass heat transfer system
SoftStart electric ignition system

Built-in Filtration System





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Interlock switch
Auto boil-out mode

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
240,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
