Vulcan 3TR65DF Gas Fryer - (3) 70 Lb Vats, Floor Model, Natural Gas

To prevent scorching while conserving energy , the Vulcan 3TR65DF natural gas fryer features a SoftStart® electronic ignition that lowers energy output to 240,000 BTU per hour during startupa€”half of the unit's overall BTU output. This three-battery unit can hold 65 to 70 pounds of oil per vat, and its KleenScreen PLUS® filtration system stains oil through a stainless steel mesh screen to remove particulate and sediment. To cook fries, mozzarella sticks, chicken, fish, and other breaded meats, it can create temperatures between 200 and 390 degrees Fahrenheit. Its ThreePass® heat transfer system evenly distributes heat throughout oil with 72 percent thermal efficiency and 60 percent cooking efficiency. For accuracy, employees can utilize its two countdown timers that can display actual or compensating time to account for temperature fluctuations.
Overall, the Vulcan 3TR65DF gas fryer measures 63 inches wide by 30 1/8 inches deep by 47 1/4 inches high. Because its cabinet and fry tank are made of stainless steel, it's durable and corrosion resistant. To hold the included 9 1/4-inch-wide by 13 1/4-inch-deep by 6-inch-high twin baskets, its fry tanks measure 19 1/2 inches wide by 14 inches deep. This unit sits on 6-inch casters, so it can be wheeled out of the way for cleaning the floor underneath. To further simplify cleaning, it includes a tank brush and clean-out rod and features an auto boil-out mode.

Product Details





Part of the PowerFry3® series
3 fryers
Per fryer capacity: 65-70 lb. (195-210 lb. total)
(4) 6-in. adjustable casters
Stainless steel cabinet and fry tank
Twin baskets feature plastic-coated handles
Maintains cooking temperatures with just 5,083 BTU per hour when idle
Includes tank brush and clean-out rod

Heat System Details





Temperature range: 200-390 degrees Fahrenheit
Solid-state digital control with melt cycles
2 countdown timers can track compensating or actual time
ThreePass heat transfer system
SoftStart electronic ignition system

Built-in Filtration System





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel filter mesh screen
1 1/4-in. port ball type drain valve
Auto boil-out mode
Interlock switch

Dimensions & Utilities





Twin baskets: 9 1/4 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 14 in. D
Overall: 63 in. W x 30 1/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
Natural gas powered
240,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
