Vulcan 3TR85AF Gas Fryer - (3) 90 Lb Vats, Floor Model, Liquid Propane

Part of the PowerFry3® series, the Vulcan 3TR85AF gas fryer features an integrated KleenScreen PLUS® filtration system that circulates 8 gallons of hot frying compound per minute to upkeep oil. Because this is a three-battery unit, it's ideal for high-volume cooking as it holds 90 pounds of oil per vat. While operators prepare fries, breaded chicken, fish, and other meats, its ThreePass® heat transfer system evenly distributes heat throughout the oil for consistency. Overall, this fryer outputs a total of 270,000 BTU, but its SoftStart® electronic ignition lowers output to 135,000 BTU per hour during startup to prevent scorching. To set temperatures between 200 and 390 degrees Fahrenheit, operators can use the unit's solid-state analog knob controls.
Overall, the Vulcan 3TR85AF gas fryer measures 63 inches wide by 34 3/8 inches deep by 47 1/4 inches high. Its stainless steel cabinet and fry tank are ideal for intense settings because it's durable and corrosion resistant. To ease the removal of old oil, this unit includes a 1 1/4-inch ball type drain valve. Its included tank brush and clean-out rod are great for precise cleaning, and since it sits on four 6-inch casters, it can be wheeled out of the way to clean the floor.

Product Details





Part of the PowerFry3 series
Battery system with 3 fryers
255-270 lb. total capacity (85-90 lb. per fryer)
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
Outputs just 5,575 BTU per hour when idle to maintain cooking temperatures
Includes tank brush and clean-out rod
(4) 6-in. adjustable casters

Heat System Details





Temperature range: 200-390 degrees Fahrenheit
Solid-state analog controls with melt cycles
ThreePass heat transfer system
SoftStart electronic ignition system

Filtration System Details





KleenScreen PLUS filtration system
18-ga. stainless steel filter pan
Stainless steel mesh screen
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Twin baskets: 8 1/4 in. W x 16 1/4 in. D x 6 in. H
Fry tanks: 19 1/2 in. W x 18 1/4 in. D
Overall: 63 in. W x 34 3/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph
LP gas powered
270,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
90000

Capacity (lbs)
270

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
270

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
968.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 90000
Capacity (lbs): 270
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 270
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
