Vulcan 3TR85AF Gas Fryer - (3) 90 Lb Vats, Floor Model, Natural Gas

The Vulcan 3TR85AF PowerFry3® floor-model fryer is comprised of three 90-pound-capacity frypotsa€”great for frying chicken, fish, dumplings, and potatoes without transferring flavor. Each vat has a corresponding solid-state analog knob control so their temperatures can be set between 200 and 390 degrees Fahrenheit. When using solid shortening, operators can choose from one of the fat-melt modes. Once the temperature is set, the SoftStart® ignition system quickly increases oil temperature, outputting 45,000 BTUs per hour to conserve energy. To yield 72 percent thermal efficiency and 60 percent cooking efficiency, it features a ThreePass® heat transfer system that effectively distributes heat through the oil to reduce lag time between recovery. Once the unit reaches the set temperature, the idle temperature setting outputs 5,575 BTUs per hour to maintain heat and reduce energy usage.
To promote user safety during frying, each fryer includes twin fryer baskets featuring plastic-coated handles that minimize heat transfer to employees' palms. The unit's base is divided into three separate cabinets so users can access the filtration system and analog controls without opening all the doors at once. This durable, 63-inch-wide by 34 3/8-inch-deep by 47 1/8-inch-tall rust- and corrosion-resistant stainless steel unit is simple to clean and can withstand daily high-volume use. Because it's fitted with four 6-inch casters, it's uncomplicated to maneuver when maintenance and cleaning are required; two of these casters can be locked to secure the unit in place during operation. Operators can drain oil from the 1 1/4-inch port ball-type drain valve and clean the tank and drain with the included tank brush and clean-out rod.
The KleenScreen PLUS® filtration system is built into the base of the Vulcan 3TR85AF high-efficiency gas fryer's cabinet on a pull-out drawer for easy access. To promote frequent filtration, it features a one-touch push button that initiates a filtration cycle. While the drain valve interlock switch automatically turns off the burners when the oil drains, the 1/3-horsepower motor and pump circulate hot oil at an 8-gallon-per-minute rate to expedite the filtration process. Its stainless steel mesh filter screen removes particulates from two sides to establish a 270-to-350-square-inch filter area. Oil is dispensed into the seamless 110-pound-capacity stainless steel filter pan, and to minimize hands-on requirements, the oil-return tube automatically adds filtered oil back to the frypots once the filter drawer is closed.

Product Details





Part of the PowerFry3 series
(3) 90-lb. frypots
SoftStart ignition system outputs 45,000 BTUs per hour to save energy while increasing oil temperature
ThreePass mechanism enhances energy efficiency
Idle temperature setting maintains temperatures at 5,575 BTUs per hour
Flue temperature doesn't exceed 750 degrees F at maximum production rate
Hi-limit shutoff mechanism
Stainless steel cabinet and frypots
6 fryer baskets (2 per frypot) feature plastic-coated handles to minimize heat transfer
Tank brush and clean-out rod included
1 1/4-in. port ball-type drain valve
(4) 6-in. adjustable casters (2 with locks)
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 90,000 BTU

Solid-state Analog Knob Controls





Separate solid-state analog knob controls for each fry tank
Located behind the cabinet doors
Electronic ignition
Operating temperature range: 200-390 degrees F
User-selectable fat-melt modes

Filtration System Details





Stainless steel mesh filter filters from 2 sides for a filter area from 270 to 350 sq. in.
1-touch button engages motor and pump
Drain valve interlock switch shuts off burners when drain valve is opened
Seamless 18-ga. stainless steel filter pan with 110-lb. oil capacity
8-GPM motor and pump
Hands-free oil-return tube

Dimensions & Utilities





63 in. W x 34 3/8 in. D x 47 1/8 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by natural gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
90000

Capacity (lbs)
270

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
270

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
968.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 90000
Capacity (lbs): 270
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 270
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
