Vulcan 3TR85DF Gas Fryer - (3) 90 Lb Vats, Floor Model, Liquid Propane

The Vulcan 3TR85DF floor model gas fryer measures 63 inches wide by 34 3/8 inches deep by 47 1/8 inches tall, creates a 36 1/4-inch-tall working height, and is divided into three fry tanks. Each frypot can hold 90 pounds of oil and includes twin fryer baskets with plastic-coated handles to reduce scalding risks when employees submerge or remove breaded meats or vegetables. The frypots and cabinet are made of stainless steela€”rugged, rust- and corrosion-resistant metal that matches most back-of-house equipment and simplifies cleaning. Its base is mounted on four 6-inch casters, two of which can lock, for smooth mobility and stabilization as needed.
With the solid-state digital controls, operators can set each fryer's temperature between 200 and 390 degrees Fahrenheit, choose from three fat-melt modes, activate two countdown timers, cook with actual or compensating time, and activate an automatic boil-out mode. A digital display provides readouts of temperatures in Fahrenheit and Celsius so users can ensure the fryers are set to the appropriate temperatures. Once temperatures and other controls are set, the SoftStart® ignition system heats oil at just 45,000 BTUs per hour per vat; the ThreePass® heat transfer system uniformly distributes the oil to enhance cooking and thermal efficiency while reducing lag times during recovery. To maintain set heat, the idle temperature setting only outputs 5,575 BTUs per hour.
Located in the base of the Vulcan 3TR85DF PowerFry3® high-efficiency fryer the KleenScreen PLUS® filtration system's pump and motor can circulate 8 gallons of hot oil per minute with the push of a button. Its stainless steel filter screen filters debris and particulate from two sides, establishing a filtration area from 270 to 350 square inches; its filtration pan can hold 110 pounds of oil. Once the oil is filtered, it can be guided back to the fry tanks with the oil-return tube.

Product Details





Part of the PowerFry3 collection
(3) 90-lb. frypots
Stainless steel cabinet and frypots
2 fryer baskets with plastic-coated handles per frypot (6 total)
(4) 6-in. adjustable casters (2 with locks)
SoftStart ignition system heats oil by outputting 45,000 BTUs per hour per frypot
ThreePass heat transfer system evenly distributes heat through oil
Idle temperature mode outputs 5,575 BTUs per hour to maintain set heat
Flue temperature doesn't exceed 750 degrees F at maximum production rate
Hi-limit shutoff mechanism
Includes tank brush and clean-out rod
1 1/4-in. port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 90,000 BTU

Solid-state Digital Controls





Electronic matchless ignition
Digital character display in Fahrenheit or Celsius
Operating temperature range: 200-390 degrees F
3 melt modes
2 countdown timers
Automatic boil-out mode
Cooks with compensating time or actual time

Filtration System Details





Stainless steel mesh filter featuring 270-350-sq.-in. filtration area
8-GPM motor and pump
1-touch button activates pump and motor
Drain valve interlock switch automatically shuts burners down when drain valve is opened
18-ga. stainless steel filtration pan with 110-lb. oil capacity
Hands-free oil-return tube

Dimensions & Utilities





63 in. W x 34 3/8 in. D x 47 1/8 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by LP gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
90000

Capacity (lbs)
270

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
270

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
968.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 90000
Capacity (lbs): 270
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 270
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 968.00
