Vulcan 3VK45AF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas

Powered by natural gas, the Vulcan 3VK45AF PowerFry5® commercial gas fryer can output 210,000 BTUs per hour. To enhance thermal and cooking efficiency, these 50-pound-capacity tanks feature a FivePass® mechanism, uniformly distributing heat throughout the oil. The SoftStart® mechanism quickly warms oil to minimize energy usage by outputting 35,000 BTUs per hour, while the idle temperature mode maintains set temperatures at just 4,251 BTUs per hour. To simplify operation, each fry tank has independent solid-state analog controls located behind the cabinet doors. Staff can set temperatures from 200 to 390 degrees Fahrenheit and initiate one of the user-selectable fat-melt modes. To keep contents in place as they're fried, each frypot includes twin fryer baskets; their plastic-coated handles enhance user safety by reducing heat transfer.
To further enhance the Vulcan 3VK45AF commercial gas fryer's efficiency, a KleenScreen PLUS® filtration unit is built into the base of the unit on a pull-out drawer. Its seamless, lightweight stainless steel filtration pan boasts a 70-pound capacity; operators can activate a filtration cycle with the push of a button. While its motor and pump circulate 8 gallons of oil per minute, the stainless steel mesh filter screen filters from two sides. Filtered oil can be directed back to the frypots with the oil-return tube.
To establish a comfortable 36 1/4-inch working height, this unit measures 46 1/2 inches wide by 30 1/8 inches deep by 47 1/8 inches tall. Its stainless steel construction is durable enough to withstand the rigors of daily back-of-house use and can simply be wiped clean. When the floor beneath it needs to be cleaned, this unit can be wheeled out of the way with ease because it's fitted with four 6-inch casters; two casters can be locked to keep the unit in place.

Product Details





Part of the PowerFry5 series
3-battery freestanding floor model with (3) 50-lb. fry tanks
Rugged, rust- and corrosion-resistant stainless steel construction
6 fryer baskets with plastic-coated handles (2 baskets per frypot)
(4) 6-in. adjustable casters (2 locking)
SoftStart ignition system warms oil while saving energy
FivePass heat transfer system yields 66 percent cooking efficiency and 78 percent thermal efficiency
Idle temperature mode outputs only 4,251 BTUs per hour to maintain heat
Flue temperature doesn't exceed 500 degrees F at maximum production rate
Hi-limit shutoff
Includes clean-out rod for drain and tank brush
1 1/4-in. port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 70,000 BTU

Solid-state Analog Knob Controls





Located behind cabinet doors
Separate solid-state analog knob controls for each fry tank
Electronic ignition
Operating temperature range: 200-390 degrees F
User-selectable fat-melt modes

Filtration System Details





Seamless, lightweight 18-ga. stainless steel filtration pan with 70-lb. oil capacity
Stainless steel mesh filter with 270-350-sq.-in. filtration area
Pump and motor circulate oil at 8 GPM
1-touch button initiates filtration cycle
Drain valve interlock switch
Hands-free oil-return tube

Dimensions & Utilities





46 1/2 in. W x 30 1/8 in. D x 47 1/8 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by natural gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
