Vulcan 3VK45DF Gas Fryer - (3) 50 Lb Vats, Floor Model, Liquid Propane

Part of the PowerFry5® series, the Vulcan 3VK45DF freestanding commercial fryer is built to save energy and extend oil life because its integrated FivePass® heat transfer system uniformly distributes heat throughout the oil. This mechanism minimizes cooking times, decreases lag between recoveries, and yields 66 percent cooking efficiency and 78 percent thermal efficiency. The SoftStart® ignition system heats oil by outputting 35,000 BTUs per houra€”half the unit's maximum hourly BTU outputa€”to reduce energy usage and prolong oil life. Its idle temperature setting maintains the desired heat by only outputting 4,251 BTUs per hour. Employees can set all three frypots' temperatures between 200 and 390, choose from three melt cycles, initiate two countdown timers, and select to use actual or compensating time. A digital display provides readouts of temperatures in Celsius and Fahrenheit so staff can monitor the heating process.
By working with the integrated energy-saving processes, the KleenScreen PLUS® filtration collection further extends oil quality. This unit is designed to be used twice a day to maintain clean, good-tasting oil, and its one-touch button simplifies startup. As much as 70 pounds of oil can be stored in its drawn stainless steel filtration pan. While the pump and motor circulate oil at 8 gallons per minute, its stainless steel mesh filter screen filters debris from two sides. Once filtering is complete, the oil-return tube returns it back to the frypots.
For durability, the Vulcan 3VK45DF commercial gas fryer's body, frypots, and fryer baskets are made of rugged, rust- and scratch-resistant stainless steel. While its 47 1/8-inch-tall structure creates a 36 1/4-inch working height, the 46 1/2-inch-wide by 30 1/8-inch-deep base is mounted on four 6-inch casters. Two of these casters include brakes to secure it in place during use.

Product Details





Part of the PowerFry5 line
Freestanding with (3) 50-lb. fry tanks
SoftStart ignition system only outputs 35,000 BTUs to save energy and quickly heat oil
FivePass heat transfer system enhances cooking and thermal efficiency
Energy-efficient idle temperature setting
Flue temperature remains below 500 degrees F at maximum production rate
Hi-limit shutoff
Stainless steel body, frypots, and fryer baskets
6 fryer baskets with plastic-coated handles (2 baskets per frypot)
(4) 6-in. adjustable casters (2 with locks)
Includes clean-out rod for drain and tank brush
1 1/4-in. port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 70,000 BTU

Solid-state Digital Controls





Electronic matchless ignition
Digital display in Fahrenheit or Celsius
Operating temperature range: 200-390 degrees F
3 melt modes
2 countdown timers
Automatic boil-out mode
Can cook with compensating time or actual time

Filtration System Details





1-touch button initiates filtration cycle
Seamless, lightweight 18-ga. stainless steel filtration pan features 70-lb. oil capacity
Pump and motor circulate oil at 8 GPM
Stainless steel mesh filter establishes 270-350-sq.-in. filtration area
Drain valve interlock switch
Hands-free oil-return tube

Dimensions & Utilities





46 1/2 in. W x 30 1/8 in. D x 47 1/8 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by LP gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
