Vulcan 3VK45CF Gas Fryer - (3) 50 Lb Vats, Floor Model, Natural Gas

To maximize throughput of shrimp, chicken, dumplings, mozzarella sticks, and fries, the Vulcan 3VK45CF PowerFry5® commercial gas fryer is built with three 50-pound-capacity frypots. Each vat comes with twin fryer baskets that contain breaded foods during frying, while their plastic-coated handles lend a secure grip and protect against heat transfer. For quick heating and reduced lag times during recovery, this unit features a FivePass® heat transfer system that yields 66 percent cooking efficiency and 78 percent thermal efficiency. The SoftStart® ignition system heats oil by outputting 35,000 BTUs per hour, aiding in saving energy and extending the oil life. Once the desired temperature is reached, the idle temperature mode only outputs 4,251 BTUS per hour to maintain the heat, further enhancing energy efficiency.
To streamline operation, each fryer has corresponding computer controls comprised of temperature adjustment from 200 to 390 degrees Fahrenheit, three melt modes, 10 menu timers, options to cook with compensating time or actual time, and a digital display; menu items can be uploaded onto the unit with a USB interface. The KleenScreen PLUS® filtration system positioned on a pull-out drawer in the fryer's base can be activated with a push of a button to promote frequent oil filtration. Its stainless steel filtration pan can hold 70 pounds of oil, while its stainless steel mesh filter screen filters particulate from two sides, establishing a filtration area as large as 350 square inches. To quicken the filtration process, its 1/3-horsepower pump and motor circulate oil at 8 gallons per minute, and the oil-return tube guides filtered shortening back to the frypots once the filter drawer is closed.
Staff can comfortably work at this Vulcan 3VK45CF high-efficiency commercial fryer because its 46 1/2-inch-wide by 30 1/8-inch-deep by 47 1/8-inch-tall structure establishes a 36 1/4-inch working height. To endure high-volume use, its stainless steel construction resists rusting, scratching, and denting; it's also simple to wipe clean to maintain a sanitary workstation. Because it's mounted on four smooth-rolling casters, it can be repositioned for cleaning or maintenance, and during use, two of its casters can be locked to secure it in place.

Product Details





Part of the PowerFry5 series
3-battery freestanding unit with (3) 50-lb. fry tanks
SoftStart ignition system saves energy and minimizes scorching
FivePass heat transfer system yields 66 percent cooking efficiency and 78 percent thermal efficiency by uniformly distributing heat throughout oil
Set heat maintained with energy-efficient idle temperature mode
Flue temperature remains below 500 degrees F at maximum production rate
Hi-limit shutoff mechanism
Made of durable stainless steel
6 fryer baskets with plastic-coated handles (2 per frypot)
(4) 6-in. adjustable casters (2 with locks)
Includes clean-out rod for drain and tank brush
1 1/4-in. port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 70,000 BTU

Computer Controls





Electronic ignition
3 melt modes
Operating temperature range: 200-390 degrees F
Digital character display in Fahrenheit or Celsius
Can cook with compensating time or actual time
10 menu timers display product name and cook time
Items can be programmed offline using USB interface (software included)

Filtration System Details





Stainless steel mesh filter establishes 270-350-sq.-in. filtration area
Seamless, lightweight 18-ga. stainless steel filtration pan with 70-lb. oil capacity
Pump and motor circulate oil at 8 GPM
1-touch button initiates filtration cycle
Drain valve interlock switch
Hands-free oil-return tube

Dimensions & Utilities





46 1/2 in. W x 30 1/8 in. D x 47 1/8 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by natural gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
150

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
150

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
46.5

Weight
717.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 150
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 150
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 46.5
Weight: 717.00
