Vulcan 3VK65AF Gas Fryer - (3) 70 Lb Vats, Floor Model, Liquid Propane

Because the Vulcan 3VK65AF commercial gas fryer is part of the PowerFry5® collection, it's built with the FivePass® heat transfer systema€”a mechanism that evenly distributes heat throughout the oil to yield 68 percent cooking efficiency and 78 percent thermal efficiency. As a result, this component reduces cooking and recovery times. To maximize throughput, this fryer is built with three 70-pound-capacity vats. Each vat comes with twin fryer baskets to keep contents contained during the frying process; the baskets' plastic-coated handles minimize heat transfer for user safety.
Users can set temperatures between 200 and 390 degrees Fahrenheit and select fat-melt modes with the analog knob controls located behind the cabinet doors. Because each vat has a separate control, foods with different requirements can be cooked simultaneously; the multi-vat design also eliminates the risk of flavor transfer. The SoftStart® ignition system quickly heats oil while only outputting 40,000 BTUs per houra€”half the unit's maximum hourly BTU output. Once the set temperature is reached, the idle temperature mode maintains temperatures by outputting 4,802 BTUs per hour for additional energy savings.
The Vulcan 3VK65AF high-efficiency, three-battery gas fryer measures 63 inches wide by 30 1/8 inches deep by 47 1/8 inches tall and is fitted with four 6-inch casters that provide smooth mobility; two casters can be locked to park the unit when necessary. For durability and corrosion resistance, it's made of stainless steel that matches other back-of-house equipment and can simply be wiped clean as needed. The KleenScreen PLUS® filtration system built into the base can be activated with the push of a button. Its stainless steel mesh filter screen filters from two sides as the pump and motor circulate oil at an 8-gallon-per-minute rate. The filtration pan can hold 110 pounds of oil, and the oil-return tube automatically sends filtered oil back to the frypots when the filter drawer is closed.

Product Details





Part of the PowerFry5 collection
Freestanding model with (3) 70-lb. fry tanks
Durable, rust- and corrosion-resistant stainless steel cabinet, frypots, and fryer baskets
6 fryer baskets with plastic-coated handles (2 baskets per frypot)
(4) 6-in. adjustable casters (2 can be locked)
SoftStart ignition system outputs 40,000 BTUs to heat oil quickly while saving energy
FivePass heat transfer system yields 68 percent cooking and 78 percent thermal efficiency
Energy-efficient idle temperature setting only outputs 4,802 BTUs per hour
Flue temperature remains below 500 degrees F at maximum production rate
Hi-limit shutoff feature
Clean-out rod for drain and tank brush included
1 1/4-in. port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 80,000 BTU

Solid-state Analog Knob Controls





Separate solid-state analog knob controls located behind the cabinet doors for each fry tank
Electronic ignition
Operating temperature range: 200-390 degrees F
User-selectable fat-melt modes

Filtration System Details





1-touch button activation
Pump and motor circulate oil at 8 GPM
Stainless steel mesh filter establishes 270-350-sq.-in. filtration area
18-ga. stainless steel filtration pan features 110-lb. oil capacity
Drain valve interlock switch
Hands-free oil-return tube

Dimensions & Utilities





63 in. W x 30 1/8 in. D x 47 1/8 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by LP gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
