Vulcan 3VK65DF Gas Fryer - (3) 70 Lb Vats, Floor Model, Liquid Propane

The Vulcan 3VK65DF commercial gas fryer is freestanding unit comprised of three 70-pound-capacity vats so staff can fry fish, shrimp, chicken, tofu, dumplings, and vegetables simultaneously at their specific cooking requirements without flavor transfer. Each frypot includes twin fryer baskets to streamline lowering foods into the vat and lifting them from the hot oil. To minimize heat transfer, the baskets' handles are coated with plastic. The vats, baskets, and cabinet are made of durable stainless steel for lasting rust, corrosion, dent, and scratch resistance throughout high-volume back-of-house use. To establish a comfortable 36 1/4-inch working height, this fryer measures 63 inches wide by 30 13/100 inches deep by 47 1/4 inches tall. It's positioned on four 6-inch casters that provide smooth mobility, and two of the casters can be locked for stability during use.
Because this fryer is part of the PowerFry5® series, it features a FivePass® heat transfer system that uniformly distributes heat, yielding 68 percent cooking efficiency and 78 percent thermal efficiency. Operators can set each frypot's temperature from 200 to 390 degrees Fahrenheit using the digital solid-state controls, and a digital display provides an accurate temperature readout in Fahrenheit or Celsius. These controls also include three melt modes for cooking solid shortening, two adjustable countdown timers, and an auto boil-out mode to streamline cleaning. Once the controls are set, the SoftStart® ignition system quickly warms oil while outputting only 120,000 BTUs per houra€”half the unit's maximum hourly BTU output. When the frypots reach set temperatures, the idle temperature setting outputs only 14,406 BTUs per hour to maintain the heat.
To promote frequent filtering, a KleenScreen PLUS® filtration unit is built into the Vulcan 3VK65DF freestanding fryer's base on a pull-out drawer for accessibility. Users can initiate a filtration cycle with the push of a button. Its pump and motor circulate oil at 8 gallons per minute, and a stainless steel mesh filter screen filters out particulates and debris from two sides, establishing a filtration area between 270 and 350 square inches. As much as 110 pounds of oil can be held in the seamless stainless steel filter pan. To minimize manual tasks, the drain oil-return tube adds filtered oil back to the frypots once the filtration drawer is closed.

Product Details





Part of the PowerFry5 VK65 collection
Freestanding floor model
3 batteries
(3) 70-lb. frypots
Stainless steel cabinet and frypots
6 fryer baskets featuring plastic-coated handles (2 per frypot)
Establishes 36 1/4-in. working height
(4) 6-in. adjustable casters (2 with locks)
FivePass heat transfer system yields 68 percent cooking efficiency and 78 percent thermal efficiency
SoftStart ignition system quickly heats oil upon startup using 120,000 BTUs per hour
Idle temperature mode outputs just 14,406 BTUs per hour to maintain set temperature
Flue temperature doesn't exceed 500 degrees F at maximum production rate
Hi-limit shutoff
Tank brushes and clean-out rods included for cleaning
1 1/4-in. full-port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 80,000 BTU

Solid-state Digital Controls





Electronic matchless ignition
Fahrenheit or Celsius digital character display
Operating temperature range: 200-390 degrees F
3 melt modes
2 countdown timers
Automatic boil-out mode
Can cook with compensating time or actual time

Filtration System Details





Positioned on pull-out drawer in base
110-lb.-capacity seamless stainless steel filter pan
Stainless steel mesh filter screen provides 270-350-sq.-in. filtration area
Filtration cycle can be activated with the push of a button
Pump and motor circulate oil at 8 GPM
Drain valve interlock switch automatically turns off burners during oil draining
Hands-free oil-return tube adds oil back to the tanks

Dimensions & Utilities





63 in. W x 30 13/100 in. D (50 1/4 in. D when doors are opened) x 47 1/4 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by LP gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
