Vulcan 3VK65DF Gas Fryer - (3) 70 Lb Vats, Floor Model, Natural Gas

So multiple foods with different cooking requirements can be fried simultaneously, the Vulcan 3VK65DF PowerFry5® efficient gas fryer is built with three 70-pound-capacity frypots. Each vat has independent digital solid-state controls that enable operators to set temperature from 200 to 390 degrees Fahrenheit, choose from three fat-melt modes, select to cook with actual or compensating time, initiate two countdown timers, and activate an automatic boil-out mode. To keep contents secured as they're lowered, fried, and lifted, all three vats come with twin fryer baskets. Their stainless steel constructions withstand exposure to high heat, while their plastic-coated handles reduce heat transfer for staff safety. Overall, this freestanding stainless steel model measures 63 inches wide by 30 13/100 inches deep by 47 1/4 inches tall and is mounted on four 6-inch castersa€”two of which include locks for stability during use.
This commercial fryer is powered by natural gas and can output 240,000 BTUs per hour across all frypots, or 80,000 BTUs per hour for each individual frypot. To minimize energy consumption, the FivePass® heat transfer system effectively distributes heat throughout oil, resulting in 68 percent cooking efficiency and 78 percent thermal efficiency. The SoftStart® ignition system outputs only 120,000 BTUs while initially heating oil to save energy and quickly warm the shortening. Once the unit reaches the set temperatures, the idle temperature settings maintains heat by outputting only 14,406 BTUs per hour.
To extend oil life, operators can initiate the Vulcan 3VK65DF commercial fryer's KleenScreen PLUS® filtration system with the push of a button. Its 1/3-horsepower pump and motor circulate oil at 8 gallons per minute, while the stainless steel mesh screen filter can remove debris from two sides, providing a filtration area as large as 350 square inches. For accessibility, this unit is positioned on a pull-out drawer in the fryer's base. As much as 110 pounds of oil can be drained into the filtration pan, and it's simple to remove for emptying as needed. The oil-return tube can simply add filtered oil back to the frypots once operators push the drawer in.

Product Details





Featured in the PowerFry5 VK65 series
Freestanding floor unit with 3 batteries
(3) 70-lb. frypots
Cabinet, frypots, and fryer baskets made of durable stainless steel
Each frypot includes 2 fryer baskets featuring plastic-coated handles
36 1/4-in. working height
Rests on (4) 6-in. adjustable casters (2 with locks)
FivePass heat transfer system yields 68 percent cooking efficiency and 78 percent thermal efficiency
SoftStart ignition system outputs 120,000 BTUs per hour to heat oil
Idle temperature mode outputs 14,406 BTUs per hour to maintain set temperature
Flue temperature doesn't exceed 500 degrees F at maximum production rate
Hi-limit shutoff system
Tank brushes and clean-out rods included
1 1/4-in. full-port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(3) 80,000 BTU

Solid-state Digital Controls





Electronic ignition
Digital character display with Fahrenheit or Celsius temperature readouts
Operating temperature range: 200-390 degrees F
3 melt modes
2 countdown timers
Automatic boil-out mode
Can cook with actual time or compensating time

Filtration System Details





Fitted on pull-out drawer in base
Stainless steel filter pan can hold 110 lb. of oil
Stainless steel mesh filter screen provides filtration areas as large as 350 sq. in.
Filtration cycle can be activated with the push of a button
Pump and motor circulate oil at 8 GPM
Drain valve interlock switch automatically turns off burners as oil is drained
Hands-free oil-return tube adds oil back to tanks

Dimensions & Utilities





63 in. W x 30 13/100 in. D (50 1/4 in. D when doors are opened) x 47 1/4 in. H
7 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by natural gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
80000

Capacity (lbs)
210

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
3

Oil Capacity (lb)
210

Oil Capacity/Fryer (lb)
70

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
63

Weight
916.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 80000
Capacity (lbs): 210
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 3
Oil Capacity (lb): 210
Oil Capacity/Fryer (lb): 70
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 63
Weight: 916.00
