Vulcan 4TR45AF Gas Fryer - (4) 50 Lb Vats, Floor Model, Natural Gas

The Vulcan 4TR45AF gas fryer measures 62 inches wide by 30 1/8 inches deep by 47 1/8 inches high and is mounted on four 6-inch casters that ease maneuvering. Its tank and cabinet are constructed of heavy-duty stainless steel, which is durable enough to withstand greasy settings. This compound unit features four vats that each hold 45 to 50 pounds of oil. The 14-inch-long by 14-inch-deep tanks accommodate twin baskets that measure 6 1/2 inches wide by 13 1/4 inches deep by 6 inches high, and because they feature plastic-coated handles, they reduce burn risks.
The Vulcan 4TR45AF gas fryer maintains optimal temperatures between 200 and 390 degrees Fahrenheit, and for straightforward operation, it features solid-state analog controls with user-selectable fat melt modes. Its SoftStart® electronic ignition heats oil quickly while reducing energy use to 140,000 BTU, and its ThreePass® heat transfer system ensures even temperatures throughout the oil. When idle, this unit requires 4,218 BTUs per hour to maintain cooking temperatures. To extend oil life, its Kleen Screen Plus® filtration system circulates frying compound at 8 gallons per minute and maintains a filter area of 270 to 350 square inches. If oil needs to be changed, its 1 1/4-inch drain valve can be used to empty old oil into the 18-gauge stainless steel filter pan. To further simplify cleaning, this unit includes a tank brush and clean-out rod.

Product Details





Part of the PowerFry3® series
4 frypots
Oil capacity per vat: 45-50 Ib.
Temperature range: 200-390 degrees F
Independent solid-state analog knob controls located behind door
User-selectable fat melt modes
ThreePassheat transfer system offers 72 percent thermal efficiency and 60.9 percent cooking efficiency
SoftStart electronic ignition system
Twin baskets feature plastic-coated handles
Stainless steel cabinet and fry tank
(4) 6-in. casters (2 locking and 2 non-locking)
Hi-limit shut-off
1 1/4-in. port ball-type drain valve

KleenScreen PLUS Filtration System





18-ga. stainless steel filter pan features 70-lb. oil capacity
Stainless steel filter mesh screen
Circulates frying compound at 8 gallons per minute
Activated by push button
Drain valve interlock switch automatically turns off gas burners
Includes high-temperature discard hose

Dimensions & Utilities





Twin baskets: 6 1/2 in. W x 13 1/4 in. D x 6 in. H
Fry tanks: 14 in. W x 14 in. D
Overall: 62 in. W x 30 1/8 in. D x 47 1/8 in. H
6 A, 1/3 HP motor
120 V/60 Hz/ 1 ph
Natural gas powered
280,000 BTU

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
200

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
4

Oil Capacity (lb)
200

Oil Capacity/Fryer (lb)
50

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
62

Weight
871.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 200
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 4
Oil Capacity (lb): 200
Oil Capacity/Fryer (lb): 50
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 62
Weight: 871.00
