Vulcan 4TR85DF Gas Fryer - (4) 90 Lb Vats, Floor Model, Liquid Propane

The Vulcan 4TR85DF PowerFry3® commercial gas fryer's freestanding, 84-inch-wide by 34 3/8-inch-deep by 47 1/4-inch-tall structure is comprised of four 90-pound-capacity frypots to maximize throughput, eliminate flavor transfer, and accommodate different cooking requirements. Each fry tank features individual solid-state digital controls, enabling users to set temperatures between 200 and 390 degrees Fahrenheit, cook with compensating or actual time, choose from one of three melt modes when using solid shortening, set two countdown timers, and activate the automatic boil-out mode. Users can quickly determine each frypot's temperature and other settings with their corresponding digital displays. Each vat comes with two stainless steel fryer baskets with plastic-coated handles to enhance user safety when dropping the baskets into and removing them from hot oil. This stainless steel unit establishes a comfortable 36 1/4-inch working height and rests on four 6-inch-diameter casters that provide smooth movement when needed.
This commercial fryer is powered by LP gas and can output 90,000 BTUs per hour for each frypota€”360,000 BTUs per hour in total. To conserve energy, its SoftStart® ignition system quickly heats oil while outputting 45,000 BTUs per frypot; the ThreePass® heat transfer system uniformly guides heat throughout oil to yield 72 percent thermal efficiency and 60 percent cooking efficiency. To maintain set temperatures, the idle temperature setting only outputs 5,575 BTUs per hour.
The Vulcan 4TR85DF efficient gas fryer's KleenScreen PLUS® filtration system can be activated with the push of a button to promote frequent filtering and extend oil life. Built into the cabinet's base, it's positioned on a pull-out drawer and includes a 110-pound-capacity stainless steel filter pan. The drain valve interlock system automatically shuts off the gas burners, while the 1/3-horsepower pump and motor circulate 8 gallons of hot shortening per minute. To establish a filtration area between 270 and 350 square inches, its stainless steel mesh filter screen eliminates particulates from two sides. By closing the filtration drawer, the oil-return tube self-seals and recycles filtered oil back to the four frypots.

Product Details





Part of the PowerFry3 VK85 line
4-battery freestanding model with 36 1/4-in. working height
(4) 90-lb.-capacity vats
Stainless steel construction
Each vat includes 2 stainless steel fryer baskets with plastic-coated handles (8 baskets total)
(4) 6-in. adjustable casters (2 with locks)
ThreePass heat transfer system evenly distributes heat throughout oil
SoftStart ignition system outputs 45,000 BTUs per hour per frypot to quickly heat oil
Idle temperature mode outputs only 5,575 BTUs per hour to maintain set temperature
Flue temperature doesn't exceed 750 degrees F at maximum production rate
Hi-limit shutoff feature
Includes tank brushes and clean-out rods
1 1/4-in. full-port ball-type drain valve
6-in. clearance required at sides and rear when placed near combustible construction
16-in. minimum clearance to adjacent open-top burner units
(4) 90,000 BTU

Solid-state Digital Controls





Electronic matchless ignition
Fahrenheit or Celsius digital character display
Operating temperature range: 200-390 degrees F
3 melt modes
2 countdown timers
Automatic boil-out mode
Cooks with compensating time or actual time

Filtration System Details





Mounted on pull-out cabinet base drawer
110-lb.-capacity 18-ga. stainless steel filter pan
Stainless steel mesh filter screen removes debris from 2 sides and establishes filtration area as large as 350 sq. in.
Pump and motor activated with push of a button
8-GPM oil circulation rate
Drain valve interlock switch automatically shuts burners off as oil drains
Hands-free oil-return tube

Dimensions & Utilities





84 in. W x 34 3/8 in. D x 47 1/4 in. H
6 A, 1/3 HP
115 V/60 Hz/1 ph, cord with NEMA 5-15P plug
Powered by LP gas
1 1/4-in. NPT common rear gas connection

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
70000

Capacity (lbs)
360

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
LP

Heat
Gas

NEMA
5-15P

Number of Fry Pots
4

Oil Capacity (lb)
360

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry3®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
84

Weight
1236.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 70000
Capacity (lbs): 360
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: LP
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 4
Oil Capacity (lb): 360
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry3®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 84
Weight: 1236.00
