Vulcan 4VK85AF Gas Fryer - (4) 90 Lb Vats, Floor Model, Natural Gas

A four-battery unit, the 4VK85AF gas fryer can hold 85 to 90 pounds of oil per frypot. For fluid, quick heating while conserving energy, its SoftStart® ignition system outputs 35,000 BTU per hour, and when the fryer reaches desired temperatures, it can maintain the heat with just 6,298 BTUs when idle. Its FivePass® heat transference system uniformly distributes heat to prevent scalding. This high-efficiency fryer is integrated with KleenScreen Plus® filtration to extend oil life and reduce premature refilling. Its 1/3-horsepower motor and pump work in tandem to circulate frying compound at 8 gallons per minute; for ample screening, its stainless steel filtration mesh screen covers 270 and 350 square inches.
This fryer is powered by natural gas and operated with independent solid-state analog controls that are located behind the door of each cabinet. Temperatures can be adjusted between 200 and 390 degrees Fahrenheit, and this unit has user-selectable fat melt modes to provide additional flexibility. Should it exceed safe temperatures, its hi-limit shut-off cuts off the burners.
The Vulcan 4VK85AF gas fryer measures 84 inches wide by 34 3/8inches deep by 47 1/4 inches high. Its fry tank and cabinet are constructed of durable stainless steel, which is ideal for high-intensity back-of-house kitchens. Each frypot includes metal twin baskets that feature plastic-coated handles to reduce heat transfer to employees' palms, and to maneuver this heavy-duty unit as needed, it sits on four 6-inch casters. For precise cleaning, a tank brush and clean-out rod are included.

Product Details





Part of the PowerFry5® series
85-90-lb. capacity per frypot
4 frypots
8 fry baskets with plastic-coated handles (2 per vat)
Stainless steel cabinet and fry tank
Adjustable casters (2 swivel locking & 2 non-locking)
1 1/4-in. full port ball type drain valve
Includes tank brush and clean-out rod
SoftStart ignition system quickly heats oil at reduced BTU rate
FivePass heat transfer system
(4) 90,000 BTUs

Solid-state Analog Controls





Temperature range: 200-390 degrees F
Fat-melt modes are user selectable
Hi-limit shut off

KleenScreen PLUS Filtration System





Motor and pump circulate compound at 8 gal. per minute
18-ga. stainless steel filter pan
Two-sided stainless steel mesh filter
Boil-out bypass function
1 1/4-in. port ball type drain valve
Interlock switch

Dimensions & Utilities





Tank size: (4) 19 1/2 in. W x 18 1/4 in. D
Baskets: (8) 8 3/4 in. W x 16 3/4 in. D x 6 in. H
Overall: 84 in. W x 34 3/8 in. D x 47 1/4 in. H
120 V/60 Hz/1 ph, with NEMA 5-15 P
7 A, 1/3-HP motor
1 1/4 NPT common rear gas connection
Powered by natural gas

Product Features
Specifications
Manufacturer
Vulcan

Baskets
2

BTU per Fryer
90000

Capacity (lbs)
360

Food Type
Breaded

Frypot Style
Tube Type

Gas Type
NG

Heat
Gas

NEMA
5-15P

Number of Fry Pots
4

Oil Capacity (lb)
360

Oil Capacity/Fryer (lb)
90

Product
Gas Fryers

Product Type
Cooking Equipment

Rating
Best

Series
PowerFry5®

Special Features
Casters Included - Uninstalled

Type
Floor Model

Warranty
1-year Limited Parts & Labor; 10-year Fry Tank

Width (in)
84

Weight
1236.00

Manufacturer: Vulcan
Baskets: 2
BTU per Fryer: 90000
Capacity (lbs): 360
Food Type: Breaded
Frypot Style: Tube Type
Gas Type: NG
Heat: Gas
NEMA: 5-15P
Number of Fry Pots: 4
Oil Capacity (lb): 360
Oil Capacity/Fryer (lb): 90
Product: Gas Fryers
Product Type: Cooking Equipment
Rating: Best
Series: PowerFry5®
Special Features: Casters Included - Uninstalled
Type: Floor Model
Warranty: 1-year Limited Parts & Labor; 10-year Fry Tank
Width (in): 84
Weight: 1236.00
