USED INGERSOLL RAND IRN75H-OF

THE INGERSOLL RAND IRN75H-OF IS A 75 HP ROTARY SCREW AIR COMPRESSOR DESIGNED FOR INDUSTRIAL APPLICATIONS. THIS UNIT OPERATES ON A 460 V, 3-PHASE, 60 HZ POWER SUPPLY WITH A TOTAL PACKAGE AMPERAGE OF 99 A AND A MAXIMUM STARTING AMPERAGE OF 99 A. IT FEATURES A VARIABLE DRIVE MOTOR AND A 120 V CONTROL VOLTAGE SYSTEM. TECHNICAL SPECIFICATIONS INCLUDE A MAXIMUM DISCHARGE PRESSURE OF 150 PSIG, A 75 HP NOMINAL DRIVE MOTOR, AND A 5.0 HP NOMINAL FAN MOTOR. THE PACKAGE INCLUDES A TRANSFORMER AND A TANK, WITH THE DRIVE COOLING FAN UNIT HAVING BEEN REPLACED IN 2023. THE EQUIPMENT WEIGHS 5,000 LBS AND HAS PHYSICAL DIMENSIONS OF 82 X 52 X 77 INCHES.
