| X | 30" | 762 mm |
| Y | 16.92" | 429.77 mm |
| Z | 17.7" | 449.58 mm |
| Power | 10 hp | 7.5 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 20 | 20 |
| Taper | Cat 40 | Cat 40 |
| Table-W | 16.92" | 429.77 mm |
| Table-L | 39.37" | 1,000 mm |
| # Axis | 4 | 4 |
| Control | CNC (Okuma OSP 5020M) | CNC (Okuma OSP 5020M) |
| Dimensions | 118 x 102 x 110 | 118 x 102 x 110 |
| Weight | 13500 | 13500 |
Specifications (subject to buyer verification):
X – Axis Travel: 30”
Y – Axis Travel: 16.92”
Z – Axis Travel: 17.70”
Table Size: 16.92” x 39.37”
Table Load Capacity: 1,100 lbs
ATC: 20
Spindle Taper: Cat 40
Spindle Speed Max: 6,000 RPM
Main Motor: 10 HP
Power: 220 V/ 480, 3 Phase, 60 HZ, 20 kVA
Dimension: 118” x 102” x 110”
Weight: 13,500 lbs
Equipped With (subject to buyer verification):
Okuma OSP5020M Controller
4th Axis
Coolant System
