NEW 2022 GENESIS IPG YLR 1500 WC

2022 Genesis IPG YLR-1500-WC Laser Welder

Key Specifications for YLR-1500-WC:
Type: Laser System
Configuration: Laser Head with Control Unit (Integrated)
Application Industry: Automotive / Industrial & Manufacturing
Application: Cutting, Drilling
Operation Mode: CW/Modulated
Wavelength: 1.07 µm
Wavelength Accuracy ±10 nm
Output Power (CW): 1500 W (Continuous Wave/Modulated)
Wavelength: 1070 nm (±10 nm)
Cooling Method: Water-cooled
Power Stability: ±0.5% to 1%
Modulation Frequency: 0 to 50 kHz
Beam Quality (M squared): Single-mode (<1.1) or multi-mode (50, 100,
200 m fiber)
Supply Voltage: 400–480 VAC, 3 Phase, 50/60 Hz
Maximum Power Consumption: 4000 - 4500 VA
Physical Dimensions: 448 x 580 x 133 mm 17.64" x 22.83" x 5.24"
Weight: < 50 kg - 70 kg

Control Interface: Analog/RS-232/Ethernet
Chiller Requirement: Approx 2.5 - 5.9 kW cooling capacity (dependent
on configuration)
Output Fiber Termination: QBH-compatible connector
Class 4 Laser Product: High-power invisible radiation

This laser is commonly found integrated into Genesis laser welding workstations
(e.g., model SYSLC0000058U).
