Specifications: Radius Capacity: 9" Heght of Std. Forming Nose: 1" Built-up Nose available: 3" Center Pin Hole - Diameter: 1" Operating Leverage: 29" Weight, Head Only: 140 lbs.
Material Capacities:
Round Mild Steel Bar: 1/2"
Square Mild Steel Bar: 3/8"
Steel Tubing - 16 Gauge: 3/4"
Standard Iron Pipe: 1/4" I.D.
Flat Steel Bar (Bent Flat): 1/4" x 1-1/2"
Flat Seel Bar (Edgewise): 1/8" x 3/4"
Angle: 1/8" x 3/4" x 3/4"
Channel: 1/8" x 3/8" x 3/4"
