USED 2023 BOBCAT T770

The 2023 Bobcat T770 is a heavy-duty, high-performance track loader built for demanding jobsites. Powered by a 92 HP turbocharged diesel engine with liquid cooling, this machine delivers reliable strength and efficiency. With a rated operating capacity of 3,475 lbs and a tipping load of 9,929 lbs, it handles tough lifting and loading tasks with ease.
Equipped with OROPS, two-speed travel, and 23 GPM standard flow auxiliary hydraulics, the T770 provides excellent control, versatility, and productivity. Its rubber tracks and low 4.2 PSI ground pressure ensure stable operation on a variety of surfaces, while the vertical lift path maximizes reach and dump height.

Engine & Power
Engine Model
Bobcat
Horsepower
92 HP
Engine Type
Turbocharged Diesel
Cooling System
Liquid Cooled
Fuel Type
Diesel
Engine Tier
Tier 4
Fuel Tank
43.8 Gallons
Hydraulic System
Standard Hydraulic Flow
23 GPM
Relief Pressure
3,500 PSI
Auxiliary Hydraulics
Yes
Working Equipment & Performance
Rated Operating Capacity
3,475 Lbs
Tipping Load
9,929 Lbs
Lift Path
Vertical
Travel Speed (Low)
6.6 MPH
Travel Speed (High)
10.7 MPH
Undercarriage & Mobility
Ground Pressure
4.2 PSI
Track Type
Rubber Tracks
Two-Speed
Yes
Dimensions
Overall Length
141.6 Inches
Overall Width
80 Inches
Overall Height
81.3 Inches
Weight
Operating Weight
10,515 Lbs
