| Swing | 35.4" | 899.16 mm |
| Machining Length | 80" | 2,032 mm |
| # Axis | 2 | 2 |
| Bar Capacity | 14.2" | 360.68 mm |
| Power | 45 kW | 60.3 hp |
| Max RPM | 1,120 RPM | 1,120 RPM |
| Tailstock | Yes | Yes |
| Control | CNC (WEILER) | CNC (WEILER) |
Maximum swing 35.40
Bar capacity 14.2”
Chuck diameter 31.00
Distance Between Centers 120″
Swing over Bed 35.4″
Swing over Cross Slide 20.9″
Cross Slide Travel 23.2″
Bed Width 23.6″
Drive Power at 60 %/100 % Duty Cycle 60/49.6 HP
Spindle Bore 14.0"
Spindle Speed 1 ~ 700 RPM
Tailstock Quill Taper MT 6
Weight 21,500 IBS
Weiler Control (Siemens)
31"Chuck
Chip Conveyor
Threading Cycle
Front and Rear 4-Jaw Chucks
