NEW 2025 GMC PBR-0510E

Equipped With
5' X 10 GA. GMC MODEL PBR-0510E POWER BENDING ROLL
New 2025
This machine was purchased new in October of 2025. It has never been put into use. It is new condition
SO 9001 certified
Taiwan machines
All (3) rolls are hardened rolls, up to 50-52 HRC
3-rollers are driven to perform high accuracy
Adjustable cone attachment included
3/8”, ½” and 5/8” grooves on rollers
One wheel one-side operated for bending roll
One wheel one-site operated for pinch roll (E model is powered)
Heavy duty casting frame
Heavy duty all steel welded construction
1/3 of full length in middle of roller is straight, and two ends with crown to get perfect round performance.
Quiet running operation
Easy swing-out top roller
Safety line all around the machine for emergency stop
All rolls run forward and reverse
Safety type forward/reverse foot pedal

STANDARD EQUIPMENT
Adjustable cone attachment
3/8”, ½” and 5/8” grooves on rollers
All (3) hardened rolls
Removable safety foot pedal
Operation & parts manual
Orange color front cover is optional.
E models come with motorized bending roll up/down w/ push button and digital display for easy operation of repeat jobs
STANDARD EQUIPMENT
Adjustable cone attachment
3/8”, ½” and 5/8” grooves on rollers
All (3) hardened rolls
Removable safety foot pedal
Operation & parts manual
Orange color front cover is optional.
E models come with motorized bending roll up/down w/ push button and digital display for easy operation of repeat jobs
SPECIFICATIONS:
Capacity Mild Steel                                         5'1" x 10 Ga.
Capacity Stainless Steel                                   5'1' x 12 Ga.
Roll Diameter                                                  4-3/4"
Min. Bending Diameter Inch                           6"
Pre-Bend Inch                                                 .012"
Rolls Opening                                                 1/2"
Main Motor                                                     3 HP  3 Phase
Approximate Weight                                       3,050 Lbs.
Approximate Dimensions                                96" x 32" x 52" H
