| Table Size-W | 15" | 381 mm |
| Table Size-L | 68" | 1,727.2 mm |
| Travel-Long | 34" | 863.6 mm |
| Travel-Cross | 12" | 304.8 mm |
| Travel-Vert | 16" | 406.4 mm |
| Power | 15 hp | 11.2 kW |
| RPM | 25 RPM | 25 RPM |
| Taper | 50 | 50 |
| Dimensions | 6-1/2’L x 6-1/2’W x 6-1/2’H | 6-1/2’L x 6-1/2’W x 6-1/2’H |
| Weight | 10,000 lbs | 10,000 lbs |
General Specifications:
Table Working Surface: 15” x 68”
Longitudinal Travel: 36”
Cross Travel: 12”
Knee Travel: 18”
Spindle Speeds: (24) 25 to 2000 RPM
Taper in Spindle: #50
Feeds: (32) 3/8 to 90 IPM
Main motor: 15 HP 220/440V
Machine Dimensions: 6-1/2’L x 6-1/2’W x 6-1/2’H
Machine Weight: 10,000 lbs
3-Way Power Rapid Traverse & Feeds
Arbor support
Coolant pump
Universal table
