USED THALMANN TZ125-6.4M

Brand – THALMANN Model – TZ125-6.4M Type – Folding Machines Year – 2017 Condition – Used – Excellent

Max Thickness (gauge): 18 gauge
Overall Length: 21′
Dimensions: 77″ W x 280″ L x 71″ H
Weight: 10,800

6.4m (21′) × 18 Gauge CNC Single Folder System Integrated Roller Shear Green LED Lights on Beam Back Stoppers Back Stopper for Short Parts Modular Tool Geometry 35° flat tool angle Allows 3:4 height/depth bending ratio 275° machining clearance Upper blade with 35° tilt 15° inclination for straight bending blade geometry Innovative Camshaft Technology Even power distribution across full machine length High angular accuracy and parallelism Camshaft kinetic system VFD (Vertical Force Drive) system Electrical Longitudinal Cutting Unit Mounted to machine frame No linear guides on bending tool Free tool travel and additional machining space Sheet Thickness Adjustment & Cambering Automatic sheet thickness adjustment via dual servomotors Dynamic crowning function Manual cambering of bending blade Automatic Striker Stop Radius range: 5–1250 mm Optional conical striker stop Safety System Complete safety concept Laser monitoring in clamping area Laser monitoring on cutting unit High-Performance STOP-and-GO Hydraulic System Adjustable Sheet Metal Support Table CNC Control Unit with Touch Screen
