NEW REVOLUTION MACHINE TOOLS B-SMART

RMT B-SMART 12' x 200 Ton precision 3 axis
CNC (Y1,Y2,X Axis) hydraulic press brake
AKAS Laser Safety IILC2000, FPSC and Laser Secure Type SS Brackets
Delem DA-53T CNC Press Brake Control - Color
LCD display- 10.1" high resolution color TFT - Hot-Key touch navigation - Control is capable of up to 4 Axis CNC - Y1,Y2,X,R), CNC Crowning (Note Standard configuration on B-SMART)
Press Brake is 3 Axis CNC - Y1,Y2 and CNC X axis back-gauge - additional Axis are optional) - Profile-53TL offline Software - 1 GB storage
Includes: Tool - Material - Product Library
Includes: USB memory stick interfacting
World class - common - hydraulic & electrical components (Rexroth - Siemens - Schneider - Hoerbiger)
High-Yield Certified European plate construction
Manual adjustable - full length wave crowning system - built into the lower bed - Includes Readout System
Interior work illumination
2 Quick-set front sheet support arms with full
length linear guide, tilting stop and T-slot - front gauging - squaring - material support
Dual - American - European section clamps ( If Optional Hydraulic Clamps are selected - Section Clamps are not included)
Tooling - Precision American upper segmented goose neck punch - * If optional hydraulic clamp is selected - This punch is no longer included *
Side and rear safety doors
Tooling - Precision ground and hardened segmented 4 Way die 2.36" Square with 5/8" x 7/8", 1 3/8" and 2" openings
Large Open Height, Large Ram Stroke, Large Throat Depth
Tooling - Precision universal die block - accepts included 4 way die - 2.36" wide tooling ( 60mm) Also has built in tang / slot for Single V dies
CNC X axis ballscrew backgauge with 2 manual Z1,Z2, R1,R2 finger assemblies - comes with 32.3" of X axis travel -Maximum Gauge-able flange with standard finger assemblies is 41.7"
