NEW BALDOR VEUHM3546

The WAGO 750-363 is a 4th generation ECO EtherNet/IP Fieldbus Coupler that connects the EtherNet/IP fieldbus system to the modular WAGO I/O system. 750-363 is a 4th generation, ECO, 3 EtherNet/IP™ Fieldbus coupler that connects the EtherNet/IP fieldbus system to the modular WAGO I/O system. The Fieldbus coupler detects all connected I/O modules and creates a local process image. It features dual Ethernet interfaces with integrated switch for line topology wiring and supports up to 64 I/O modules without bus extension.
Specification
Value
Brand
Baldor
Model/Part Number
VEUHM3546
Rated Horsepower
1 HP
Base RPM
1770 RPM
Synchronous Speed
1800 RPM
Voltage
208/230/460V
Phase
3 Phase
Frequency
60 Hz
Full Load Amps
3.1A @ 208V, 3.0A @ 230V, 1.5A @ 460V
Frame Size
56C
Enclosure Type
TEFC (Totally Enclosed Fan Cooled)
Mounting Type
C-Face Footless
Shaft Diameter
0.625 inches
Overall Length
13.23 inches
Service Factor
1.15
Frame Material
Steel
Insulation Class
F
Full Load Efficiency
85.5%
Motor Type
3520M Unit Handling
Rotation
Reversible
Number of Speeds
1
Bearings
Ball
IP Rating
44
Weight
39 lbs
Standards Met
UL, CE, CSA
We warranty all items for 30 days from date of purchase.

SKU: AI0233
UPC: 679523686185
Condition: New
Availability: In Stock
Weight: 42.00 LBS
Width: 16.00
(in)
Height: 16.00
(in)
Depth: 24.00
(in)
Shipping: Calculated at Checkout
GTIN: 679523686161
Full Load Amps: 3.1A @ 208V, 3.0A @ 230V, 1.5A @ 460V
Manufacturer: Baldor
Shaft Diameter: 0.625 in
Enclosure Type: TEFC
Part Number: VEUHM3546
Shelf: PR-TOP
Model: VEUHM3546
MPN: VEUHM3546
Type: AC Motor
