USED 1998 TOSHIBA MACHINE BTD-110.R16
Overview
Tosnuc 888 CNC Control
4.3" Spindle Diameter
CAT 50 | 3,000 rpm | 38 ATC
Table Size/Weight: 63" x 55.1" | 13,860 lbs
Travels: X-78.7" / Y-59.1" / Z-57.1" / W-19.7"
The Toshiba Machine BTD-110.R16 is an exclusive part of our Boring Mills, Horizontal, Table Type, CNC inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
Specs
CNC Control: yes
Control Type: Tosnuc 888
Spindle Diameter: 4.3"
Table Size: 63" x 55.1"
Max Table Load: 13,860 pounds
X-Axis Travel: 78.7"
Y-Axis Travel: 59.1"
Z-Axis Travel: 57.1"
W-Axis Travel: 19.7"
B-Axis (Pallet Indexing): 0.001°
Spindle Taper: CAT 50
Spindle Speed: 3,000 rpm
Spindle Motor: 20 hp
Tool Changer Capacity: 38
Coolant Thru Spindle: yes
Machine Weight: 61,600 pounds
Equipped With
- Tosnuc 888 CNC Control
- Coolant Thru Spindle
- Chip Conveyor
- Coolant Tank
