SN: N/A, (460/60/3 electrics), S-4692
Standard Specifications:
- (4) 1-1/2 HP, 208-220/440/60/3 direct drive spindles (1 w/cemco
multi-spindle boring head)
- (1) spring loaded work-piece hold-down clamps
- 22" x 96" plywood table providing for 14" x 96" total boring area
- Single cycle or automatic mode from 0 to 30 strokes per minute
- Ball bearing type spindles, (1-1/2" min. center capability)
- Hydraulic spindle feed via 2 HP self contained hydraulic pump
- 6" adjustable stroke, (head carriage moves to stationary work table)
- 96" x 42" x 94" approximate overall dimensions
- Weighs approximately 3,000 lbs.
Condition: Used
Stock Number: S-4692
