ROSENQUIST 482RO-EP-2 ELECTRO-FLOW CONTINUOUS FEED-THROUGH RADIO-FREQUENCY GLUER
Overview
Description
ROSENQUIST 482RO-EP-2 ELECTRO-FLOW CONTINUOUS FEED-THROUGH RADIO-FREQUENCY GLUER
(460/60/3 electrics), H-1385
The Gluing “system” consists of a conveyorized glue spreader / infeed section / press-gluer section / out feed section / flying cut-off saw
Following are general brochure specifications, (to be verified as they may not exactly apply to this gluer)
- 100" wide by 2" thick material capacity at 20 feet per minute maximum production capability
- Up to 2,000 square inches of glue line per minute curing capacity
- 20 KW solid state generator located and mounted above the press
- Conveyorized glue-spreader with in-feed chain conveyor table
- Hydraulic edge pressure and feed drive system
- Edge clamping pressure is applied with precision crowding system
- (4) 19" long by 24" wide material contact tracks on 25” centers, (top and bottom)
- Fixed height bottom tracks & individual top tracks that provide the pneumatic clamping pressure
- Hydraulic driven tracks to insure smooth & dependable operation with independent retard control of each track
Specifications
Condition: Used
Stock Number: H-1385
